COLORADOSOLOBAR6 | 24-CELL IP65-RATED RGBWWL FULL-SPECTRUM LED BATTEN WITH HIGH OUTPUT AND LONG THROW
COLORADOSOLOBAR6
24-CELL IP65-RATED RGBWWL FULL-SPECTRUM LED BATTEN WITH HIGH OUTPUT AND LONG THROW
COLORADOSOLOBAR6
24-CELL IP65-RATED RGBWWL FULL-SPECTRUM LED BATTEN WITH HIGH OUTPUT AND LONG THROW
- UM : EA
- Estimated Weight: 67.0
COLORado Solo Bar 6 is a 24-cell IP65-rated RGBwWL LED batten that produces a full range of color and perfect whites from a fixture offering LDs the flexibility to easily create beautiful whites with RGBwW or take control of all five colors in the full RGBwWL array. COLORado Solo Bar 6 seamlessly combines homogenized squares for phenomenal end-to-end direct-view pixel-mapped looks, with the high output and long throw to perform equally well as a cyc, footlight, or traditional batten down light. Its advanced IP65 design brings lighter weight and all-weather durability together in one fixture at home both on the road and in permanent installations. A selection of beam shaping filters is included to broaden the choice of projection effects. Control is via DMX, ArtNet or sACN. With improved and simplified rigging options, virtually silent operation, and flawless performance live or on camera, COLORado Solo Bar 6 brings new versatility to touring, festivals, televised and theatrical productions.
Features:
- Delivers superior color rendering with a 95 CRI and linear CCT presets from 2800 K to 8000 K.
- Built with an IP65-rated housing for durable, all-weather use in touring or permanent installs.
- Supports DMX, RDM, CRMX, Art-Net, and sACN for flexible and comprehensive control.
- Includes beam shaping filters and an integrated glare shield for enhanced optical control.
- Provides smooth 18-bit dimming and silent operation ideal for broadcast and studio applications.
- Features adjustable mounting brackets and guide pins for simple, seamless end-to-end alignment.
| Light Source | 24 (RGBWwL) LED Engines |
|---|---|
| Color Temperature (range) | 2800 to 8000 K |
| Color Temperature (at full) | 9167 K |
| CRI | 95 |
| Beam Angle | 16.7° |
| Beam Angle (w/CYC Diffusion) | 40.7° |
| Beam Angle (w/Half Diffusion) | 18.9° |
| Beam Angle (w/Stealth Diffusion) | 25° |
| Field Angle | 36.1° |
| Field Angle (w/CYC Diffusion) | 84.4° |
| Field Angle (w/Half Diffusion) | 46.8° |
| Field Angle (w/Stealth Diffusion) | 61.2° |
| Lumens | 25,198 |
| Lumens (w/CYC Diffusion) | 32,913 |
| Lumens (w/Half Diffusion) | 23,920 |
| Lumens (w/Stealth Diffusion) | 8,571 |
| Illuminance | 5,834 lux @ 5 m |
| Illuminance (w/CYC Diffusion) | 1,739 lux @ 5 m |
| Iluminance (w/Half Diffusion) | 3,788 lux @ 5 m |
| Iluminance (w/Stealth Diffusion) | 932 lux @ 5 m |
| Selectable PWM | 1,000 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 12,000 Hz, 25,000 Hz |
| Power Connection | Edison (Local) plug to Seetronic Powerkon IP65 |
| Power Input | Seetronic Powerkon IP65 |
| Power Output | Seetronic Powerkon IP65 |
| Data Connectors | 5-pin IP65 XLR, Seetronic etherCON® compatible |
| Cable Length (power) | 5 ft (1.5 m) |
| Software Connection | USB |
| Control Protocol | Art-Net, sACN, DMX, CRMX, RDM |
| Modes/Personalities | 72 personalities |
| Certifications | CE, MET, FCC, UKCA |
| IP Rating | IP65, temporary outdoor use, with pressure equalizing M12 GORE valve |
| Temperature (Ambient) | -4 °F to 113 °F (-20 °C to 45 °C) |
