CONTROL 47LP | LOW PROFILE VERSION OF C47C/T -SAME SPECS, EXCEPT ONLY 142 MM (5.6 IN) DEEP, 68 HZ TO 20 KHZ

  • MAP: $255.00 / EA
  • List Price: $315.32 / EA
  • Log in to see if custom discounts apply
  • Minimum Order Quantity: 2
  • Case Quantity: 2
  • Sign In or Submit RFQ for accurate lead times
LOW PROFILE VERSION OF C47C/T -SAME SPECS, EXCEPT ONLY 142 MM (5.6 IN) DEEP, 68 HZ TO 20 KHZ
LOW PROFILE VERSION OF C47C/T -SAME SPECS, EXCEPT ONLY 142 MM (5.6 IN) DEEP, 68 HZ TO 20 KHZ
LOW PROFILE VERSION OF C47C/T -SAME SPECS, EXCEPT ONLY 142 MM (5.6 IN) DEEP, 68 HZ TO 20 KHZ
LOW PROFILE VERSION OF C47C/T -SAME SPECS, EXCEPT ONLY 142 MM (5.6 IN) DEEP, 68 HZ TO 20 KHZ
Click image to enlarge
LOW PROFILE VERSION OF C47C/T -SAME SPECS, EXCEPT ONLY 142 MM (5.6 IN) DEEP, 68 HZ TO 20 KHZ
LOW PROFILE VERSION OF C47C/T -SAME SPECS, EXCEPT ONLY 142 MM (5.6 IN) DEEP, 68 HZ TO 20 KHZ
LOW PROFILE VERSION OF C47C/T -SAME SPECS, EXCEPT ONLY 142 MM (5.6 IN) DEEP, 68 HZ TO 20 KHZ
LOW PROFILE VERSION OF C47C/T -SAME SPECS, EXCEPT ONLY 142 MM (5.6 IN) DEEP, 68 HZ TO 20 KHZ

CONTROL 47LP
LOW PROFILE VERSION OF C47C/T -SAME SPECS, EXCEPT ONLY 142 MM (5.6 IN) DEEP, 68 HZ TO 20 KHZ

  • UM : EA
  • Estimated Weight: 20.0

The Control 47LP is a low-profile loudspeaker designed for installation in areas with limited above-ceiling clearance, featuring a depth of 5.6 inches. It is based on the same platform as the Control 47C/T and provides a coverage angle of 120 degrees. The system is suitable for various applications including restaurants, retail spaces, and large casinos.

  • Shallow Backcan Version for limited clearance
  • Same Sonic Signature as Control 47C/T for mixing and matching
  • Proprietary Conical RBI Technology for wide, consistent coverage
  • Flat Frequency Response and Superior Performance
  • Elegant design fits any décor
    • Frequency Range 68 Hz - 20 kHz
    Power Rating 150 W Continuous Program Power, 75 W Continuous Pink Noise, 300 W peak
    Sensitivity 91 dB (1 kHz - 16 kHz)
    Transformer Taps 60 W, 30 W, 15 W, 7.5 W @ 70 V, plus transformer bypass
    Coverage Angle 120° conical, constant directivity
    Impedance 8 ohms (in bypass mode)
    Input Connectors Two removable locking 2-pin connectors with screwdown terminals
    Color White
    Safety Agency Suitable for use in air handling spaces per UL1480, UL2043, NFPA90 & NFPA 70; UL Listed signaling speaker; Transformer UL registered per UL1876; IEC60849/EN60849 compliant
    Plenum Usage Yes, backcan included
