OVATIONB565FC | OVATION B-565FC INCLUDES: POWERCON POWER CORD, COLOR BLENDING FILTER CONTROL:

  • MAP: $1,148.50 / EA
  • List Price: $1,294.50 / EA
  • Log in to see if custom discounts apply
  • Case Quantity: 1
  • Sign In or Submit RFQ for accurate lead times
OVATION B-565FC INCLUDES: POWERCON POWER CORD, COLOR BLENDING FILTER CONTROL:
OVATION B-565FC INCLUDES: POWERCON POWER CORD, COLOR BLENDING FILTER CONTROL:
Click image to enlarge
OVATION B-565FC INCLUDES: POWERCON POWER CORD, COLOR BLENDING FILTER CONTROL:
OVATION B-565FC INCLUDES: POWERCON POWER CORD, COLOR BLENDING FILTER CONTROL:

OVATIONB565FC
OVATION B-565FC INCLUDES: POWERCON POWER CORD, COLOR BLENDING FILTER CONTROL:

  • UM : EA
  • Estimated Weight: 13.0

Ovation B-565FC boasts groundbreaking features such as an RGBA-Lime color system and the incorporation of RDM, Art-Net and sACN plus standard DMX for programming and networking options. This little powerhouse not only makes a great batten-style light, but is also a tremendous standard wash. A holographic filter is included and locks into place so the fixture can be used in any orientation with no worry about the filter sliding out.

Features:

  • Houses 56 RGBA-Lime LEDs to produce a rich and expanded color spectrum.
  • Delivers exceptionally smooth fades with 16-bit dimming of master and individual colors.
  • Includes a lockable holographic filter for creating a smooth, elliptical wash.
  • Eliminates on-camera flicker with adjustable Pulse Width Modulation for broadcast applications.
  • Engineered for nearly silent operation, ideal for noise-sensitive studio and theatre use.
  • Offers a virtual color wheel and an expansive 2800 K to 10000 K CCT range.

Light Source56 LEDs (12 red, 12 green, 12 blue, 8 amber, 12 lime) 3 W, (650 mA), 50,000 hours life expectancy
Color Temperature (range)2800 K to 10000 K
CRI (3200 K)80
Installed Optics20°
Beam Angle (horizontal)19°
Beam Angle (vertical)20°
Beam Angle (horizontal w/filter)36°
Beam Angle (vertical w/filter)20°
Field Angle (horizontal)37°
Field Angle (vertical)37°
Field Angle (horizontal w/filter)66°
Field Angle (vertical w/filter)40°
Lumens6,523
Illuminance1,637 lux @ 5 m
Illuminance (w/filter)470° @ 5 m
Selectable PWM600 Hz, 1200 Hz, 2000 Hz, 4000 Hz, 6000 Hz, 25,000 Hz
Power ConnectionEdison (Local) plug to Neutrik® powerCON®
Power InputNeutrik® powerCON®
Power OutputNeutrik® powerCON®
Data Connectors3- and 5-pin XLR, Amphenol etherCON® Compatible
Cable Length (power)5 ft (1.5 m)
CertificationsCE, MET, FCC
IP RatingIP20, dry location
