DCI4X600DA | DCI 4|600DA - 4 CHANNEL POWER AMPLIFIER 600W @ 4OHM,70V 100V, WITH DANTE AES67 NETWORKED AUDIO
DCI4X600DA
DCI 4|600DA - 4 CHANNEL POWER AMPLIFIER 600W @ 4OHM,70V 100V, WITH DANTE AES67 NETWORKED AUDIO
DCI4X600DA
DCI 4|600DA - 4 CHANNEL POWER AMPLIFIER 600W @ 4OHM,70V 100V, WITH DANTE AES67 NETWORKED AUDIO
- UM : EA
- Estimated Weight: 20.0
For applications that require Dante or AES67 networked audio, the Crown DriveCore Install DA Series provides a balanced combination of output power, channel count and speaker load flexibility along with proprietary DriveCore technology for superb efficiency and exemplary audio quality. The DCi DA Series includes a high-powered DSP with JBL speaker tunings, network control/monitoring, and the ability to drive 2/4/8/16 ohm, 70V and 100V speaker loads. The amp’s advanced capabilities and support for Dante Domain Manager makes it perfect for installations that have standardized on Dante for networked audio transport.
Features:
- Integrated dante / aes67 networked audio – simplifies installation by enabling dante / aes67 networked audio signals to be sent directly to the amplifier. provides flexibility of installation options available with crown / harman's expansive line-up of drivecore install amplifiers. includes support for dante 4.0 firmware for integration with dante domain manager.
- Network configuration, monitoring & control – better monitoring, control and audio manipulation with the hiqnet protocol over standard tcp/ip network. the hiqnet audio architect software allows for remote configuration, monitoring, and control of all aspects of the dci-da series amplifiers.
- Programmable general purpose input/output port – gpio ports can be configured in many different ways, such as volume controls, recall presets, or to report errors to third-party control system.
- DSP capabilities include the following: LevelMAX Limiters, Input/Output EQ, Crossover, Delay, Matrix Mixer, Speaker Line Monitoring
| Output channels | 4 |
|---|---|
| Frequency response (8ω, 20hz - 20khz) | ±0.25dB |
| Total harmonic distortion (at full rated power, 20hz - 20khz) | 0.35% |
| Damping factor (20hz to 100hz) | >1000 |
| Load impedance (stereo/dual mode) | 2Ω - 16Ω 70Vrms and 100Vrms |
| Load impedance bridge mono | 4Ω - 16Ω 140Vrms and 200Vrms |
| Cooling | Continuously variable speed forced air, front to back airflow |
| Maximum fan noise (re dba spl @ 1m) | 45 |
| Required ac mains (±10%) | 100V-240V ~ 50/60Hz |
| Power connector | 15A IEC |
