SBH10 | 140 X 10 DEGREE, 8 X 5" COAXIAL HIGH PERFORMANCE COLUMN STYLE SPEAKER
SBH10
140 X 10 DEGREE, 8 X 5" COAXIAL HIGH PERFORMANCE COLUMN STYLE SPEAKER
SBH10
140 X 10 DEGREE, 8 X 5" COAXIAL HIGH PERFORMANCE COLUMN STYLE SPEAKER
- UM : EA
- Estimated Weight: 100.0
Danley’s SBH Series with Danley’s patented Paraline technology are completely different from any of the multi-cone column products currently on the market. In fact, Danley’s SBH speakers actually feature a large horn with an effective path length of over 25 feet (SBH10 model). This yields superior performance with unparalleled pattern control – without spurious lobes or complicated processing for proper performance. That reality makes Danley’s SBH Series a perfect option for anywhere intelligibility is required in reverberant spaces. Perfect applications of the SBH Series includes houses of worship, public assembly halls, airports, train stations, public transit hubs, stadiums, arenas, and/or retail kiosks.
|
Coverage Pattern |
140° horizontal, 10° vertical |
|
Operating Frequency Range |
77Hz-15KHz +/- 3dB, |
|
Continuous Output |
127 dB SPL |
|
Peak Output |
133 dB SPL |
|
Sensitivity |
99 dB SPL measured at 10 meters at 28.3V input |
|
Driver Complement |
8 x 5" coaxial drivers, |
|
Weight |
100 lbs |
|
Rated Impedance |
4 Ohm |
|
Power Rating |
1,300W continuous, |
