VFB16B | VERSAFIT IN-WALL SYSTEM (BLACK)
VFB16B
VERSAFIT IN-WALL SYSTEM (BLACK)
Click image to enlarge
VFB16B
VERSAFIT IN-WALL SYSTEM (BLACK)
- UM : EA
- Estimated Weight: 9.6
VersaFit in-wall box by Crimson is a unique mounting component perfect for retrofit and new construction applications. Complete the solution by choosing from over 20 different Crimson mounts from ultra-flat to full articulating. Two standard size knockouts for electrical boxes that comply with all US electrical codes.
Features:
- Mountable with pre-construction or retrofit installations
- Self measuring and leveling feature for offset to 1/2″ and 5/8″ drywall
- Includes screw and pre-drilled hole for ground wire connection
- Two different standard size knockouts comply with all US electrical codes for pre-construction and retrofit installations
- Use box to hide additional electronics
- Interfaces with 8 standard Crimson pivot or full articulating arms for a flush to the wall installation
- Interfaces with over 20 different standard Crimson mounts including flat, ultra-flat, tilting, pivoting and full articulating
| TV size range | 32" – 65"+ |
|---|---|
| Compatible mounts | A30F, A32F, A34, A37F, A40, A55, A55V, A63F, A65, A80, F46, F55, F63, FU46, FU55, FU60, FU65, P30F, P32F, P37F, P55V, P65, T46, T46L, T55, T55L, T63, T63L, T80 |
| Depth in wall | 3.5" (89mm) |
| Mounting surface | wood stud, concrete or cinder block |
| Stud spacing | dual stud 16" on center |
| Construction | aluminum/high-grade cold rolled steel |
| Product finish | scratch resistant epoxy powder coat |
| Product weight | 8.4lb (3.8kg) |
| Package specifications | 18.5"x17.3"x4.5" |
| Color | black |
| Warranty | 10-years |
×
×
