AC115S | 15" SUBWOOFER WITH 75MM (3 IN) VOICE COIL. (PRICED AS EACH)

  • MAP: $940.00 / EA
  • List Price: $1,128.00 / EA
  • Log in to see if custom discounts apply
  • Case Quantity: 1
  • Sign In or Submit RFQ for accurate lead times
15" SUBWOOFER WITH 75MM (3 IN) VOICE COIL. (PRICED AS EACH)
15" SUBWOOFER WITH 75MM (3 IN) VOICE COIL. (PRICED AS EACH)
15" SUBWOOFER WITH 75MM (3 IN) VOICE COIL. (PRICED AS EACH)
Click image to enlarge
15" SUBWOOFER WITH 75MM (3 IN) VOICE COIL. (PRICED AS EACH)
15" SUBWOOFER WITH 75MM (3 IN) VOICE COIL. (PRICED AS EACH)
15" SUBWOOFER WITH 75MM (3 IN) VOICE COIL. (PRICED AS EACH)

AC115S
15" SUBWOOFER WITH 75MM (3 IN) VOICE COIL. (PRICED AS EACH)

  • UM : EA

The AC115S is a 15-inch (385 mm) subwoofer system featuring a single low-frequency driver in a vented, front-loaded cabinet designed to extend bandwidth. The rectangular enclosure includes M10 threaded suspension points for flexible mounting options. This model is part of the JBL AE Application Engineered Series intended for fixed installation applications.

  • High power, long excursion driver for low frequencies
  • High sensitivity, low power compression
  • Large port for high output, low-frequency reinforcement
  • Multiple attachment points for flexibility
  • Robust 18 mm plywood with textured black finish
Frequency Range (-10dB) 32 Hz - 250 Hz
Frequency Response (±3 dB) 40 Hz - 250 Hz
System Sensitivity (1W @ 1m) 94 dB
Nominal Impedance 8ohms
Maximum SPL (1m) 120 dB (126 dB peak)
System Power Rating 500W (2000W peak), 2 hrs (AES rated), 400W/800W/1600W (Continuous/Program/Peak) (IEC rated)
LF Driver 1 x 15" woofer, 385 mm driver with 75 mm voice-coil
Input Connector Dual Neutrik NL4MP connectors, covered barrier trip terminals
Enclosure 18 mm multi-ply hardwood plywood
Baffle Powder coated, 1.5 mm perforated steel, with acoustically transparent black foam backing
Finish Textured black paint finish
Suspension Attachment 12 x M10 threaded suspension points
Nominal LF Driver Impedance 8ohms
