ATW-3211NDE2 | 3000 SERIES NETWORK WIRELESS (4TH GEN): ATW-R3210N RECEIVER & ATW-T3201 BODYPACK TRANSMITTER

Overall System

Operating Frequencies

Band DE2: 470.125 to 529.975 MHz (2395 frequencies), Band EE1: 530.000 to 589.975 MHz (2400 frequencies), Band EF1: 590.000 to 649.975 MHz (2400 frequencies), Band FG1: 650.000 to 699.875 MHz (1996 frequencies)

Operating Frequencies

Band DE2: 470.125 to 529.975 MHz (2395 frequencies), Band EE1: 530.000 to 589.975 MHz (2400 frequencies), Band EF1: 590.000 to 649.975 MHz (2400 frequencies), Band FG1: 650.000 to 699.875 MHz (1996 frequencies), Please note that some frequency bands might not be available in your territory or could come with a limited tuning bandwidth / transmitting power due to local regulations.

Minimum Frequency Step

25 kHz

Modulation Mode

FM

Maximum Deviation

ATW-T3201: ±38 kHz (THD:10%), ATW-T3202: ±36 kHz (THD:10%)

Frequency Response

ATW-T3201: 31 Hz to 15,500 Hz, ATW-T3202: 25 Hz to 16,700 Hz, Frequency response depends on attached microphone element

Operating Range

100 m (328'), Open range environment with no interfering signals.

Total Harmonic Distortion

<1.0% (at 1 kHz, ±17.5 kHz deviation)

Operating Temperature Range

-5° C to +45° C (23° F to 113° F)

Simultaneous Use

40 Channels per band*, For assistance with multi-band operation or other frequency coordination issues, please contact your regional Audio-Technica customer service representitive. *Region and band dependent

Handheld Transmitter

RF Power Output

High: 30 mW, Low: 10 mW (switchable), at 50 ohms

Spurious Emissions

Following Federal and National Regulations

Microphone Capsule

Interchangable industry standard thread

Battery Type

Two 1.5V AA, not included

Battery Life

High: 8.0 hours (alkaline), Low: 9.0 hours (alkaline), High: 9.0 hours (Ni-MH 1900mAh), Low: 9.5 hours (Ni-MH 1900mAh), Depending on battery type, usage, and environmental conditions.

Dimensions

ATW-T3202 (without capsule): 193 mm (7.60") long, 37 mm (1.46") maximum diameter, ATW-T3202/C510: 265 mm (10.43") long, 54 mm (2.13") maximum diameter, ATW-T3202/C710: 271 mm (10.67") long, 50 mm (1.97") maximum diameter

Net Weight

ATW-T3202 (without capsule): 200 g (7.1 oz), without batteries, ATW-T3202/C510: 330 g (11.6 oz), without batteries, ATW-T3202/C710: 314 g (11.1 oz), without batteries

Body Pack

RF Power Output

High: 30 mW, Low: 10 mW (switchable), at 50 ohms

Battery Life

High: 8.0 hours (alkaline), Low: 9.0 hours (alkaline), High: 9.0 hours (Ni-MH 1900mAh), Low: 9.5 hours (Ni-MH 1900mAh), Depending on battery type, usage, and environmental conditions.

Battery Type

Two 1.5V AA, not included

Dimensions

64 mm x 82 mm x 23 mm (W x D x H), 2.52" x 3.22" x 0.91" (W x D x H)

Input Connections

cH-style screw-down 4-pin connector, Pin 1: GND, Pin 2: INST INPUT, Pin 3: MIC INPUT, Pin 4: DC BIAS +5V

Net Weight

102 g (3.6 oz), without batteries

Spurious Emissions

Following Federal and National Regulations

High-pass (low-freq. roll-off)

125Hz, 12dB/octave

Receiver

Receiving System

True Diversity

Image Rejection

60 dB nominal

RF Sensitivity

20 dBuV at 60 dBA S/N ratio (50 ohms termination)

Maximum Output Level

XLR, balanced: +14 dBV, 6.3 mm (1/4"), unbalanced: +8 dBV

Antenna Input

BNC-type, 50 ohms

Antenna Power

12 V DC, 160 mA (combined)

Power Supply

100-240V AC (50/60 Hz) to 12V DC 1A (center positive) switched mode external power supply

Dimensions

210.0 mm x 191.0 mm x 43.4 mm (W x D x H), 8.27" x 7.52" x 1.71" (W x D x H)

Weight

1100 g (38.8 oz), without accessories

Accessories Included

Two flexible UHF antennas; AC adapter (country dependent); rack-mount Adapters
