AU65 | WORLD'S THINNEST ARTICULATING MOUNT FOR 13" TO 65" SCREENS
AU65
WORLD'S THINNEST ARTICULATING MOUNT FOR 13" TO 65" SCREENS
Click image to enlarge
AU65
WORLD'S THINNEST ARTICULATING MOUNT FOR 13" TO 65" SCREENS
- UM : EA
- Estimated Weight: 14.6
Securely holds flat panel displays a mere 1.09″ from the wall when retracted and a full 20″ when extended. Features include smooth tilt adjustments of +15° forward and 3° side-to-side roll, three attachment points for wood studs or concrete walls for additional installation safety and security, a built in level for quick and easy installation and an integrated cable management system that preserves design and decor aesthetics.
Features:
- OSHPD approved for seismic safety
- VESA compatible up to 600x400mm
- Smooth variable tilt of 15°
- Three wall attachment points offers additional safety
- Post-installation leveling without requiring tools
- Snap in place mechanism to lock position when retracted
- Built in level for perfect placement
- Decorative cover hide screw head and level after installation
- Integrated cable management for clean look
| TV size range | 13" – 65" |
|---|---|
| Weight capacity | 80lb (36kg) |
| Max mounting pattern | 600x400mm |
| VESA mounting patterns | 100x100mm, 200x100mm, 200x200mm, 300x100mm, 300x200mm, 300x300mm, 400x300mm, 400x400mm, 600x400mm |
| Depth from wall | 1.09" (27.8mm) |
| Max extension | 20" (508mm) |
| Tilt | +15°/-5° |
| Pivot | 180° |
| Roll (side to side) | 3° |
| Mounting surface | wood stud, concrete or cinder block |
| Stud spacing | single stud |
| Construction | aluminum/high-grade cold rolled steel |
| Product finish | scratch resistant epoxy powder coat |
| Product weight | 14.6lb (6.6kg) |
| Package specifications | 28"x18"x3" |
| Color | black |
| Warranty | 10-years |
×
×
