C 5:4X | 500W 4CH AMP WITH NOMADLINK NETWORK MONITORING & DEDICATED CONTROL FOR INSTALL

  • Call for Price
  • Log in to see if custom discounts apply
  • Case Quantity: 0
  • Usually ships in 3-7 days
500W 4CH AMP WITH NOMADLINK NETWORK MONITORING & DEDICATED CONTROL FOR INSTALL
500W 4CH AMP WITH NOMADLINK NETWORK MONITORING & DEDICATED CONTROL FOR INSTALL
Click image to enlarge
500W 4CH AMP WITH NOMADLINK NETWORK MONITORING & DEDICATED CONTROL FOR INSTALL
500W 4CH AMP WITH NOMADLINK NETWORK MONITORING & DEDICATED CONTROL FOR INSTALL

C 5:4X
500W 4CH AMP WITH NOMADLINK NETWORK MONITORING & DEDICATED CONTROL FOR INSTALL

  • UM : EA
  • Estimated Weight: 22.5

The C 5:4X is a Versatile Four-Channel Amplifier, Delivering 4 × 125 W* at 4 OHMS, 8 OHMS, 16 OHMS or 70 VRMS; 250 W at 100 VRMS is Available in Bridge Mode.

FEATURES

  • - 500 Watt, 4-channel amplifier with up to 125 Watts output per channel and NomadLink network for monitoring and control
  • - Selectable gain plus scalable Voltage Peak Limiter (VPL) and bridge-mode operation allow custom configuration for any application
  • - 4 x 125 Watts into 4 -16 Ohms low impedance or 70 V constant voltage
  • Proven and reliable Class-D output stage delivers sonic purity and efficiency
  • - Power Factor Correction (PFC) and switch mode power supply reduces running costs and minimizes environmental impact
  • - Intuitive DeviceControl software monitors and controls key functions via the NomadLink network
  • - Comprehensive protection scheme including current, voltage, DC, temperature, short circuit and open load warnings
  • - Fixed 35 Hz high pass filter, switchable per channel for sub sonic speaker protection
  • - 4 x balanced analog audio inputs on 3-pin Phoenix* connectors
  • - 4 x barrier strip 2-pole screw terminal output connectors
  • - Removable dust filter grille for increased air circulation
  • - Compact and durable 2U rackmount chassis saves space in install applications
  • - GPIO connectors with power control and indication for 3rd party system integration
  • - Universal power supply served through an IEC mains connector
  • - 10-Year Warranty Program*
  • - Designed and engineered in Sweden
