COLORDASHPARH7XIP | RGBWAUV LED wash,2664 lumen output,flicker-free output w/ multiple PWM frequencies
COLORDASHPARH7XIP
RGBWAUV LED wash,2664 lumen output,flicker-free output w/ multiple PWM frequencies
COLORDASHPARH7XIP
RGBWAUV LED wash,2664 lumen output,flicker-free output w/ multiple PWM frequencies
- UM : EA
- Estimated Weight: 8.0
In the rig or on the floor, live or on camera, indoor or out, the compact COLORdash PAR H7X IP RGBWAUV LED wash efficiently delivers a broad palette of subtle to saturated color with beautiful precision, weighing in under 8 lbs while delivering over 2,600 lumens of output. Flawlessly smooth 16-bit fades with four selectable dimming curves. Flicker-free output with multiple PWM frequencies. Punch up a hot pink, mix a delicate pastel, pick a perfectly calibrated Kelvin color temperature, or trigger intense strobe effects. With RDM to remotely choose its DMX personality and an OLED display to easily read its onboard menu, the COLORdash PAR H7X IP offers convenient operation and excellent performance as an IP65-rated all-weather die-cast workhorse at home in any environment.
Features:
- Features 7 hex-color (RGBAW+UV) LEDs that produce a powerful 2,664-lumen output.
- Achieve precise color mixing with hex-color LEDs and a 2800K to 10,000K CCT range.
- Built with a rugged, IP65-rated die-cast housing for reliable all-weather operation.
- Supports both DMX and RDM protocols for flexible remote addressing and control.
- Ensures flicker-free on-camera performance with adjustable Pulse Width Modulation settings.
- Offers four selectable dimming curves for exceptionally smooth, professional-grade fades.
| Light Source | 7 LEDs (hex-color RGBAW+UV) 84 W, (513 mA), 50,000 hours life expectancy |
|---|---|
| Color Temperature (range) | 2800 to 10,000 K |
| Color Temperature (at full) | 11,477 K |
| Beam Angle | 23° |
| Field Angle | 37.9° |
| Lumens | 2664 |
| Illuminance (total) | 583 lux @ 5 m |
| Selectable PWM | 600, 1.2k, 2k, 4k, 6k, 25k Hz |
| Power Connection | Edison (Local) plug to Seetronic Powercon IP65 |
| Power Output | Seetronic Powercon IP65 |
| Data Connectors | 3- and 5-pin XLR, 3- and 5-pin IP65 XLR |
| Cable Length (power) | 5 ft (1.5 m) |
| Control Protocol | DMX, RDM |
| DMX Channels | 6ch ,8ch ,9ch ,13ch, or 14ch |
| Modes/Personalities | 5 personalities (6ch, 8ch, 9ch, 13ch, or 14ch) |
| Certifications | CE, MET, FCC, UKCA |
| IP Rating | IP65, temporary outdoor/wet use |
| Temperature (Ambient) | -4 °F to 113 °F (-20 °C to 45 °C) |
