CONTROL 126W | PREMIUM IN-WALL TWO-WAY LOUDSPEAKER WITH 6-1/2" (165 MM) WOOFER. POLYMER-COATED ALUMINUM-CONE
CONTROL 126W
PREMIUM IN-WALL TWO-WAY LOUDSPEAKER WITH 6-1/2" (165 MM) WOOFER. POLYMER-COATED ALUMINUM-CONE
CONTROL 126W
PREMIUM IN-WALL TWO-WAY LOUDSPEAKER WITH 6-1/2" (165 MM) WOOFER. POLYMER-COATED ALUMINUM-CONE
- UM : EA
CONTROL 126W is an in-wall loudspeaker from the JBL Professional Control Contractor series. It is intended for installation in environments including boardrooms, reception areas, airports, convention centers, cruise ships, retail outlets, restaurants, museums, and surround sound locations. The design emphasizes minimal visual impact while delivering sound performance suitable for foreground music and critical listening applications.
Features:
- 165 mm polymer-coated aluminum-cone woofer with butyl rubber surround
- 25 mm pure-titanium dome swivel aimable tweeter
- High-slope crossover for natural midrange sound
- Frequency response: 38 Hz – 20 kHz
- Power handling: 50 W continuous, 100 W program, 200 W peak
| Frequency Range | 38 Hz - 20 kHz (-10 dB) |
|---|---|
| Power Rating | 200 W Peak, 100 W Continuous Program, 50 W Continuous Pink Noise |
| Sensitivity | 88 dB SPL |
| Coverage Angle | 180°H x 160°V |
| Impedance | 8ohms |
| Drivers | LF: 165 mm polymer-coated aluminum cone; HF: 25 mm pure-titanium dome with cloth suspension on low-diffraction swivel-mount with -10 degree aimability |
| Input Connectors | Screw-down Euroblock-type connector, max wire size 14 AWG (1.5 mm) |
| Crossover Network | 3rd order (18 dB/oct) Low Pass to woofer, 3rd order (18 dB/oct) High Pass to tweeter |
| Included Accessories | Cutout template and paint shield |
