CQUAD63 | CEILING MOUNTED QUAD DISPLAY SYSTEM FOR 37" TO 70" MONITORS, INCLUDES A UNIVERSAL MOUNTING INTERFACE

  • MAP: $2,078.39 / EA
  • List Price: $2,596.79 / EA
  • Log in to see if custom discounts apply
  • Case Quantity: 1
  • Sign In or Submit RFQ for accurate lead times
CEILING MOUNTED QUAD DISPLAY SYSTEM FOR 37" TO 70" MONITORS, INCLUDES A UNIVERSAL MOUNTING INTERFACE
CEILING MOUNTED QUAD DISPLAY SYSTEM FOR 37" TO 70" MONITORS, INCLUDES A UNIVERSAL MOUNTING INTERFACE
Click image to enlarge
CEILING MOUNTED QUAD DISPLAY SYSTEM FOR 37" TO 70" MONITORS, INCLUDES A UNIVERSAL MOUNTING INTERFACE
CEILING MOUNTED QUAD DISPLAY SYSTEM FOR 37" TO 70" MONITORS, INCLUDES A UNIVERSAL MOUNTING INTERFACE

CQUAD63
CEILING MOUNTED QUAD DISPLAY SYSTEM FOR 37" TO 70" MONITORS, INCLUDES A UNIVERSAL MOUNTING INTERFACE

  • UM : EA
  • Estimated Weight: 141.4

Attaches to standard 1.5″ threaded extension columns. Can be used as retrofit on existing columns or combine with Crimson E-series fixed extensions or EA-series adjustable extensions and Crimson CA8HD ceiling adapter to complete the solution. Compatible with all 1.5″ NPT threaded pipe.

Features:

  • Pre-assembled components are easily bolted together
  • System ships in standard boxes, not requiring special shipping and handling arrangements or charges
  • 360º of post-installation lockable rotation of entire system
  • Lockable rotation of each screen (limited only by size of TV) for flexible configuration angles
  • Up to 20º of pin-locking incremental tilt adjustment
  • Post installation screen leveling without use of tools
  • Pre-sorted hardware pack for easy installation
Weight capacity 125lb (57kg) per screen
Rotation (yaw) 360°
Mounting interface 1.5" NPT thread compatible
Construction high-grade cold rolled steel
Product finish scratch resistant epoxy powder coat
Product weight 47.7lb (21.6kg)
Color black
Warranty 10-years
