CSA2120R | 2 X 120 WATT AMPLIFIER AT 4/8 OHMS

  • MAP: $580.00 / EA
  • List Price: $580.00 / EA
  • Log in to see if custom discounts apply
  • Case Quantity: 1
  • Sign In or Submit RFQ for accurate lead times
2 X 120 WATT AMPLIFIER AT 4/8 OHMS
2 X 120 WATT AMPLIFIER AT 4/8 OHMS
2 X 120 WATT AMPLIFIER AT 4/8 OHMS
Click image to enlarge
2 X 120 WATT AMPLIFIER AT 4/8 OHMS
2 X 120 WATT AMPLIFIER AT 4/8 OHMS
2 X 120 WATT AMPLIFIER AT 4/8 OHMS

CSA2120R
2 X 120 WATT AMPLIFIER AT 4/8 OHMS

  • UM : EA

The CSA2120R is a two-channel power amplifier designed for commercial and installed sound applications. It features analog front-end processing and operates with a switch-mode universal power supply.

Features:

  • 2 x 120W at 4/8ohms
  • Plenum Rated (UL2043)
  • Compact size and lightweight
  • Convection cooled
  • Auto-standby mode for energy savings
  • Summing RCA inputs for each channel
Output 120W @ 4/8ohms (1kHz, THD+N<0.5%)
Frequency Response +/- 1dB (@1W into 4 or 8ohms)
Load Impedance Stable from 2 - 16ohms
Sensitivity 1.4Vrms
Signal to Noise Ratio >100 dB (1kHz, A-weighted)
Input Impedance Balanced 20Kohms / Unbalanced 10Kohms
Max Input +20dBu Typical
