CSS-H30 | 30W PAGING HORN

The CSS-H30 is a 30-watt paging horn designed for public address, paging, intercom, security, alarm, and industrial use. It features an IP-65 rating for weather resistance, enabling operation in both indoor and outdoor environments. The horn has a focused coverage pattern intended to project sound over greater distances compared to wider coverage horns.

• Clear voice range for announcements and paging
• High sensitivity for loud sound with low power
• 50° horizontal by 70° vertical coverage for long throw
• Phenolic diaphragm driver for outdoor durability
• UL-registered 30W multi-tap transformer with 8 ohm bypass
• Built-in high-pass filter protects against low frequency damage
• Weather-resistant with stainless steel bracket and hardware

Frequency Range	380 Hz – 6 kHz
Coverage Angle	50°H x 70°V
Included High-Pass Filter	Passive 350 Hz high-pass filter
Directivity Factor (Q)	15.8 at 2 kHz
Directivity Index (DI)	12 at 2 kHz
Power Rating	30 W (120 W peak), 100 hours
Sensitivity	108 dB average (1 kHz – 6 kHz), 112 dB at 1.4 kHz
Maximum SPL	123 dB continuous average, 129 dB peak (1 kHz – 6 kHz)
Impedance	8 ohms direct; multiple transformer taps available
Outdoor Capability	IP-65 rated, salt spray resistant, stainless steel hardware
