DR-10X | MINI PORTABLE RECORDER FOR XLR MICROPHONE
DR-10X
MINI PORTABLE RECORDER FOR XLR MICROPHONE
DR-10X
MINI PORTABLE RECORDER FOR XLR MICROPHONE
- UM : EA
- Estimated Weight: 0.5
TASCAM’s compact DR-10X attaches to a handheld microphone for the ultimate compact news gathering recording system. A captive XLR connector attaches firmly to your microphone, capturing interviews at 48kHz/24-bit Broadcast WAV resolution. Offload recordings through the microUSB connection or by removing the microSD card.
Features
Support for MP3 recording at both 128kbps and 192kbps
Level meters are now active during both recording and playback
Level selection with dual recording function added
POLY file dual recording
Overall performance improvements
|
Recording media |
microSD card (64MB to 2GB), |
|
microSDHC card (4GB to 32GB) |
|
|
Media discharging |
Push-Push type (Guard cover mounted) |
|
Recording format |
|
|
V1.00 |
|
|
WAV |
44.1k / 48k Hz, 16 / 24-bit mono/poly WAV (BWF format) |
|
V2.00 |
|
|
WAV |
44.1k / 48k Hz, 16 / 24-bit mono/poly (BWF format) |
|
MP3 |
44.1k / 48k Hz, 24-bit mono/poly |
|
Recording |
128k / 192k bps |
|
Playback |
32k to 320k bps |
|
Analog audio Inputs |
|
|
Connector |
XLR-3-31 × 1 |
|
Input Impedance |
10kO or more |
|
MIC input gain |
LOW / MID / HIGH |
|
PHONES |
|
|
Connector |
1/8" (3.5mm) Stereo Mini jack (DUAL MONO) × 1 |
|
USB |
|
|
Connector |
USB Micro-B type × 1 |
|
Maximum Output |
USB2.0 HIGH SPEED mass storage class |
|
Power |
1 AAA batteries (Alkaline or NiMH), USB bus power |
|
Battery Operation Time |
|
|
Alkaline batteries (EVOLTA) |
Aprrox. 10 hours |
|
Battery (RTC) |
Lithium × 1(built in with soldering) |
|
Dimensions |
2.1" × 3.7" × 1.1" / 52 × 94.4 × 28 mm |
|
Weight |
2.4 oz. / 68.3 g (including batteries), 1.99 oz. / 56.3 g (excluding batteries) |
|
Accessories |
USB cable, Owner's Manual (including warranty) |
