EVEF50Z | LED FRESNEL FIXTURE THAT SHINES A SOFT-EDGED, WARM WHITE SPOT AND FEATURES D-FI™ USB
EVEF50Z
LED FRESNEL FIXTURE THAT SHINES A SOFT-EDGED, WARM WHITE SPOT AND FEATURES D-FI™ USB
EVEF50Z
LED FRESNEL FIXTURE THAT SHINES A SOFT-EDGED, WARM WHITE SPOT AND FEATURES D-FI™ USB
- UM : EA
- Estimated Weight: 16.5
EVE F-50Z is an LED Fresnel fixture that shines a soft-edged, warm white spot and features D-Fi™ USB compatibility for wireless master/slave or DMX control. It’s designed for mobile and installation applications. Manual zoom gives you the flexibility to project from any distance. You can operate EVE F-50Z in standalone mode eliminating the need for DMX control and you can save time running extension cords by power linking multiple units.
Features
Stylish, compact Fresnel perfect for small to medium stages and theatres
Warm white LED with high CRI show the true natural colors of scenery and cast
Flexibility to project from any distance using the manual zoom
D-Fi USB compatibility for wireless Master/Slave or DMX control
powerCON-compatible power input/output connections for power linking
Included Barn Doors keeps light where you need it
Included Gel Frame adds a splash of color to any scene
|
DMX Channels |
1 or 3 |
|
DMX Connectors |
3-pin XLR |
|
Light Source |
1 LED (warm white) 50 W, (1.3 A), 50,000 hours life expectancy |
|
Beam Angle |
(Narrow): 17° (Wide): 50° |
|
Zoom Angle |
(manual): 17° to 50° |
|
Illuminance |
(17°): 4,780 lux @ 2 m, (50°): 998 lux @ 2 m, (17°): 853 lux @ 5 m, (50°): 156 lux @ 5 m |
|
Power Linking |
16 units @ 120 V; 26 units @ 230 V |
|
Input voltage |
100 to 240 VAC, 50/60 Hz (auto-ranging) |
|
Power and Current |
60 W, .5 A @ 120 V, 60 Hz; 58 W, .3 A @ 230 V, 50 Hz |
|
Weight |
8.41 lb (3.9 kg) |
|
Size |
11.1 x 8.3 x 13 in (281 x 212 x 328 mm) |
|
Approvals |
CE, MET |
|
Accessory Holder/Gel Frame Size |
6.25 in (158 mm) |
|
Color Temperature |
3500 K |
|
CRI |
92 |
|
Bracket Mounting Hole |
M12 |
|
Optional Controllers |
D-Fi USB |
