EW-D EM (R4-9) | EWD DIGITAL SINGLE CHANNEL RECEIVER (HALF RACK). INCLUDES RACKMOUNT KIT

  • MAP: $329.00 / EA
  • List Price: $379.00 / EA
  • Log in to see if custom discounts apply
  • Case Quantity: 3
  • Sign In or Submit RFQ for accurate lead times
EWD DIGITAL SINGLE CHANNEL RECEIVER (HALF RACK). INCLUDES RACKMOUNT KIT
EWD DIGITAL SINGLE CHANNEL RECEIVER (HALF RACK). INCLUDES RACKMOUNT KIT
Click image to enlarge
EWD DIGITAL SINGLE CHANNEL RECEIVER (HALF RACK). INCLUDES RACKMOUNT KIT
EWD DIGITAL SINGLE CHANNEL RECEIVER (HALF RACK). INCLUDES RACKMOUNT KIT

EW-D EM (R4-9)
EWD DIGITAL SINGLE CHANNEL RECEIVER (HALF RACK). INCLUDES RACKMOUNT KIT

  • UM : EA
  • Estimated Weight: 6.0

Versatile and feature-rich digital wireless system for those who sing, speak or play instruments that allows for seamless product pairing and management via the EW-D Smart Assist App. Receive state-of-the-art live sound.

Features:

  • Digital transmission operating in the UHF spectrum greatly enhances range, reliability and scalability
  • Smart Assist App connects via Bluetooth Low Energy for a streamlined setup and operation at a distance
  • Auto scan creates reliable connections with minimal time and effort
  • 134 dB audio input dynamic range eliminates need for sensitivity adjustments and preserves every detail
  • Elimination of intermodulation enables channels to be placed in an equidistant tuning grid 600 kHz apart
  • 56 MHz of tuning bandwidth and equidistant spacing enables up to 90 channels
  • 2,240 selectable frequencies allow for fine tuning
  • Lithium-Ion battery pack (sold separately) delivers up to 12 hours of operation (up to 8 hours of operation with 2x provided AA batteries)
Total harmonic distortion (THD) ≤ -60 dB for 1 kHz @ -3 dBfs input level
Latency (ms) 1.9 ms
Audio frequency response 20 Hz - 20 kHz (-3 dB) @ 3 dBfs
Audio output level 18 dBu max.
Dynamic range (>) 134 dB
Operating relative humidity (≤ %) 5 - 95 % (non-condensing)
Operating temperature (C) -10 °C - +55 °C (14 °F - 131 °F)
Charging current (mA) < 300 mA
Input voltage 11 - 13 V
Transmission power (mA) BLE: max. 10 mW EIRP
Dimensions 212 x 44 x 189 mm
Height (mm) 73
Length (mm) 405
Weight (g) approx. 1000 g (without antennas and power supply)
Width (mm) 350
Product height 44 mm (1.73")
Product weight (g) approx. 1000 g (2.2 lbs)
Product width 189 mm (7.44")
Bluetooth transmission frequency 2402 - 2480 MHz
