EW-D SK (R4-9) | DIGITAL BODYPACK TRANSMITTER W/ 1/8" AUDIO INPUT SOCKET (EW CONNECTOR), R4-9 (552 - 608 MHZ RANGE)

  • MAP: $329.00 / EA
  • List Price: $379.00 / EA
  • Log in to see if custom discounts apply
  • Case Quantity: 4
  • Sign In or Submit RFQ for accurate lead times
DIGITAL BODYPACK TRANSMITTER W/ 1/8" AUDIO INPUT SOCKET (EW CONNECTOR), R4-9 (552 - 608 MHZ RANGE)
DIGITAL BODYPACK TRANSMITTER W/ 1/8" AUDIO INPUT SOCKET (EW CONNECTOR), R4-9 (552 - 608 MHZ RANGE)
Click image to enlarge
DIGITAL BODYPACK TRANSMITTER W/ 1/8" AUDIO INPUT SOCKET (EW CONNECTOR), R4-9 (552 - 608 MHZ RANGE)
DIGITAL BODYPACK TRANSMITTER W/ 1/8" AUDIO INPUT SOCKET (EW CONNECTOR), R4-9 (552 - 608 MHZ RANGE)

EW-D SK (R4-9)
DIGITAL BODYPACK TRANSMITTER W/ 1/8" AUDIO INPUT SOCKET (EW CONNECTOR), R4-9 (552 - 608 MHZ RANGE)

  • UM : EA
  • Estimated Weight: 2.1

Versatile and feature-rich digital wireless system for those who sing, speak or play instruments that allows for seamless product pairing and management via the EW-D Smart Assist App. This bodypack transmitter is compatible with a wide range of Sennheiser headset microphones and clip-on/lavalier microphones.

Features:

  • Digital transmission operating in the UHF spectrum greatly enhances range, reliability and scalability
  • Smart Assist App connects via Bluetooth Low Energy for a streamlined setup and operation at a distance
  • Auto scan creates reliable connections with minimal time and effort
  • 134 dB audio input dynamic range eliminates need for sensitivity adjustments and preserves every detail
  • Elimination of intermodulation enables channels to be placed in an equidistant tuning grid 600 kHz apart
  • 56 MHz of tuning bandwidth and equidistant spacing enables up to 90 channels
  • 2,240 selectable frequencies allow for fine tuning
  • Lithium-Ion battery pack (sold separately) delivers up to 12 hours of operation (up to 8 hours of operation with 2x provided AA batteries)
Total harmonic distortion (THD) ≤ -60 dB for 1 kHz @ -3 dBfs input level
Latency (ms) 1.9 ms
Audio frequency response 20 Hz - 20 kHz (-3 dB) @ 3 dBfs
Dynamic range (>) 134 dB
Operating relative humidity (≤ %) 5 - 95 % (non-condensing)
Operating temperature (C) -10 °C - +55 °C (14 °F - 131 °F)
Charging current (mA) < 300 mA
Input voltage 2.0 - 4.35 V
Transmission power (mA) Audio link: 10 mW ERP (Range Y1-3: 12 mW ERP) BLE: max. 10 mW EIRP
Dimensions 63 x 80 x 20 mm (without antenna)
Height (mm) 73
Length (mm) 350
Weight (g) approx. 120 g
Width (mm) 81
Product height 80 mm (3.15")
Product weight (g) approx. 120 g (0.26 lbs)
Product width 20 mm (0.79")
Bluetooth transmission frequency 2402 - 2480 MHz
