EW-DP EK (R4-9) | PORTABLE DIGITAL UHF RECIEVER, FOR EW-D BODYPACK/EW-D SKM-S HANDHELD/EW-DP SKP TRANSMITTER
EW-DP EK (R4-9)
PORTABLE DIGITAL UHF RECIEVER, FOR EW-D BODYPACK/EW-D SKM-S HANDHELD/EW-DP SKP TRANSMITTER
_1.png)
_2.png)
EW-DP EK (R4-9)
PORTABLE DIGITAL UHF RECIEVER, FOR EW-D BODYPACK/EW-D SKM-S HANDHELD/EW-DP SKP TRANSMITTER
- UM : EA
If you want to stand apart from the content creation crowd, quality is key. Especially for filmmakers. Because anyone can create content, but not everyone can create art. Many of the wireless audio products for solo and freelance filmmakers operate in the crowded 2.4 GHz band, making them unreliable and prone to dropouts and excessive noise due to Bluetooth and Wi-Fi interference. You need a streamlined, hassle-free, reliable audio solution for filmmaking that takes you away from the noise of the crowd and empowers you to achieve your creative vision.
| Latency (ms) | 1.9 ms |
|---|---|
| Total harmonic distortion (THD) | ≤ -60 dB for 1 kHz @ -3 dBfs input level |
| Audio frequency response | 20 Hz - 20 kHz (-3 dB) @ 3 dBfs |
| Audio output level | < 2 dBV max. (high level) / < 4dBU max (high level) |
| Dynamic range (>) | 134 dB |
| Operating relative humidity (≤ %) | 5 - 95 % (non-condensing) |
| Operating temperature (C) | -10 °C - +55 °C (14 °F - 131 °F) |
| Charging current (mA) | Typ. < 250 mA / Max. < 400 mA (BA 70) / Typ. < 400 mA / Max. < 750 mA (2x AA batteries) < 300 mA@5 V (USB-C standalone) |
| Impedance | < 50 mW into 16 Ohms |
| Input voltage | ~ 1.8 - 4.35 V |
| Transmission power (mA) | BLE: max. 10 mW EIRP |
| Dimensions | 86 x 67 x 28 mm (3.39" x 2.64" x 1.1") |
| Height (mm) | 63 |
| Length (mm) | 315 |
| Weight (g) | 586 |
| Width (mm) | 196 |
| Product height | 86 mm (3.39") |
| Product weight (g) | approx. 140 g (0.31 lbs) |
| Product width | 28 mm (1.1") |
| Bluetooth transmission frequency | 2402 - 2480 MHz |
