FSE-BP50-X5 | FREESPEAK EDGE BELTPACK: 5GHZ WITH (9) ASSIGNABLE KEYS, 5 PIN XLR-FEMALE HEADSET

  • MAP: $3,105.00 / EA
  • List Price: $3,105.00 / EA
  • Log in to see if custom discounts apply
  • Case Quantity: 0
  • Sign In or Submit RFQ for accurate lead times
FREESPEAK EDGE BELTPACK: 5GHZ WITH (9) ASSIGNABLE KEYS, 5 PIN XLR-FEMALE HEADSET
FREESPEAK EDGE BELTPACK: 5GHZ WITH (9) ASSIGNABLE KEYS, 5 PIN XLR-FEMALE HEADSET
FREESPEAK EDGE BELTPACK: 5GHZ WITH (9) ASSIGNABLE KEYS, 5 PIN XLR-FEMALE HEADSET
FREESPEAK EDGE BELTPACK: 5GHZ WITH (9) ASSIGNABLE KEYS, 5 PIN XLR-FEMALE HEADSET
FREESPEAK EDGE BELTPACK: 5GHZ WITH (9) ASSIGNABLE KEYS, 5 PIN XLR-FEMALE HEADSET
Click image to enlarge
FREESPEAK EDGE BELTPACK: 5GHZ WITH (9) ASSIGNABLE KEYS, 5 PIN XLR-FEMALE HEADSET
FREESPEAK EDGE BELTPACK: 5GHZ WITH (9) ASSIGNABLE KEYS, 5 PIN XLR-FEMALE HEADSET
FREESPEAK EDGE BELTPACK: 5GHZ WITH (9) ASSIGNABLE KEYS, 5 PIN XLR-FEMALE HEADSET
FREESPEAK EDGE BELTPACK: 5GHZ WITH (9) ASSIGNABLE KEYS, 5 PIN XLR-FEMALE HEADSET
FREESPEAK EDGE BELTPACK: 5GHZ WITH (9) ASSIGNABLE KEYS, 5 PIN XLR-FEMALE HEADSET

FSE-BP50-X5
FREESPEAK EDGE BELTPACK: 5GHZ WITH (9) ASSIGNABLE KEYS, 5 PIN XLR-FEMALE HEADSET

  • UM : EA

The FSE-BP50-X5 is a multi-channel beltpack designed for use in the ISM license-free 5 GHz frequency range. It features a water-resistant construction and an ergonomic form factor.

The device includes nine programmable keys, a large color display, two dedicated encoders labeled A and B, individual level controls for channels C and D, and a master volume control. The FreeSpeak Edge Digital Wireless RF Configuration Guide provides detailed and usage guidelines for the 5 GHz band and RF channels.

Features:

  • TFT color display
  • 4 top buttons with individual level control
  • 5 additional programmable buttons
  • Rotary controls on both sides and up/down level controls
  • Master volume control
  • Mic and speaker mode
  • Drop-in and usb-c charging
  • Compatible with freespeak edge base, arcadia central station, and e-ipa-hx cards
  • 5 ghz tuner frequency
  • 20-27 tuner channels (region specific)
  • Robust tuner link for high multipath or reflective environments
  • Dual redundant tuners
  • 2.4 ghz tuner with beltpack pairing and firmware updates over the air
  • Low latency audio (<35ms)
  • Ip54 rating for wet and dusty conditions
Audio bandwidth200 – 12khz
No. of full-duplex audio paths9
Mode of operationFull duplex on all routes
Level/talk controls9 push buttons, 5 level controls (2 rotary, 2 button, 1 master)
Menu button1
Headset connector4-pin male, clear-com standard; options for 5-pin female and 7-pin male with ptt
Microphone typeElectret and dynamic, selectable in beltpack menu
Headset limiterSelectable from beltpack menu
Frequency spectrum5170 - 5875 mhz (20 mhz channels set by country)
Output powerAdjustable from 1 – 24 dbm (max power depends on channel and country)
