FSII-BP19-X4 | FREESPEAK II BELTPACK: 1.9GHZ
FSII-BP19-X4
FREESPEAK II BELTPACK: 1.9GHZ
Click image to enlarge
FSII-BP19-X4
FREESPEAK II BELTPACK: 1.9GHZ
- UM : EA
The FSII-BP19-X4 is a rugged, water-resistant beltpack operating in the ISM license-free 1.9 GHz frequency range. It provides high audio bandwidth designed for improved intelligibility and listening performance.
FreeSpeak II 1.9 beltpacks with firmware version 5.3.32.0 and later support Bluetooth headsets.
Features:
- Compatible with FreeSpeak BASE-II, FreeSpeak Edge Base, Arcadia Central Station, Eclipse HX via E-IPA cards
- Operates 1.9, 2.4, and 5.0 GHz beltpacks on a single system
- Supports up to 200 beltpacks on a single system
- Encoder volume swap between A&C and B&D
- Listen Again message replay
- Simple 2-channel partyline to 5-channel intercom on the same beltpack
- Over-the-air beltpack registration
- 1.9 GHz radio frequency
- Typical range 300 ft (90 m), outdoor range 800 ft (240 m)
- Robust radio link for high multipath or reflective environments
- Supports Bluetooth headset connection up to version 5.1
- IP53 rating for wet and dusty conditions
- 18+ hour battery life
| Audio Bandwidth | 200Hz-7.5KHz |
|---|---|
| No. of Full-Duplex Audio Paths | Up to 5 with individual level control |
| Mode of Operation | Full duplex on all routes |
| Level/Talk Controls | 4 pushbuttons, a reply button and 2 rotary controls |
| Enter/Answer-Back Button | 1 |
| Bluetooth | Yes |
| Headset Connector | 4-pin male |
| Microphone Type | Electret and Dynamic, selectable in beltpack menu |
| Modulation | GFSK, TDMA frame 10ms Full and Long slot |
| Battery Life | 18+ hours with Li-Ion; 9 hours with 3 x Alkaline AA cells |
×
×
×
×
