FSII-BP19-X4-O2 | FREESPEAK II O2 BELTPACK: 1.9GHZ
FSII-BP19-X4-O2
FREESPEAK II O2 BELTPACK: 1.9GHZ
Click image to enlarge
FSII-BP19-X4-O2
FREESPEAK II O2 BELTPACK: 1.9GHZ
- UM : EA
The FSII O2 1.9 GHz beltpack is specifically designed to work in Hyperbaric chambers safely, operating at atmospheric pressures of 5.1 atm, 517 kPa, or 75 psi with a change of +/- 26 psi per minute without damage.
Features:
- Compatible with FSII base, FreeSpeak Edge base, Arcadia Central Station, E-IPA-HX card, FSII splitter hardware
- Operates at atmospheric pressure up to 75 psi
- Indoor range up to 300 ft (90 m)
- Outdoor range up to 800 ft (240 m)
- 1.9 and 2.4 GHz beltpacks operate on single system
- Supports 65 to 90 beltpacks per system
- Encoder Volume Swap between A&C and B&D channels
- "Listen Again" message replay
- Simple 2-channel partyline to 5-channel intercom operation
- Over-the-air beltpack registration
- XLR-4M headset connector
- IP53 rating for wet and dusty conditions
- Built-in flashlight
- Uses AA alkaline or rechargeable Nickel Metal Hydride batteries
| Audio Bandwidth | 200Hz-7.5KHz |
|---|---|
| No. of Full-Duplex Audio Paths | Up to 5 with individual level control |
| Mode of Operation | Full duplex on all routes |
| Level/Talk Controls | 4 pushbuttons, a reply button and 2 rotary controls |
| Enter/Answer-Back Button | 1 |
| Headset Connector | 4-pin male |
| Microphone Type | Electret and Dynamic, selectable in beltpack menu |
| Headset Limiter | Selectable from beltpack menu |
| Modulation | GFSK, TDMA frame 10ms Full and Long slot |
| Battery Life | 9+ hours |
×
×
×
×
×
