FSII-BP19-X7 | FREESPEAK II BELTPACK: 1.9GHZ, (2) GPI
FSII-BP19-X7
FREESPEAK II BELTPACK: 1.9GHZ, (2) GPI
Click image to enlarge
FSII-BP19-X7
FREESPEAK II BELTPACK: 1.9GHZ, (2) GPI
- UM : EA
The FSII-BP19-X7 is a rugged, water-resistant beltpack designed to operate within the ISM license-free 1.9 GHz frequency band. It provides high audio bandwidth to facilitate clear audio communication.
Beltpacks with firmware version 5.3.32.0 and above support Bluetooth headset connectivity.
Features:
- Compatible with FreeSpeak BASE-II, FreeSpeak Edge Base, Arcadia Central Station, and Eclipse HX via E-IPA cards
- Operates on 1.9, 2.4, and 5.0 GHz frequencies on a single system
- Supports up to 200 beltpacks per system
- Encoder volume swap between A&C and B&D
- Listen Again message replay
- Supports 2 to 5 channel partyline operation on the same beltpack
- Over-the-air beltpack registration
- Typical range 300ft (90m), outdoor range 800ft (240m)
- Robust radio link for multipath and reflective environments
- Supports Bluetooth headset connection up to version 5.1
- IP53 rating for wet and dusty conditions
- 18+ hour battery life
- FSII 1.9 GHz radio frequency
- Simple 2-channel to 5-channel intercom
- CC-110
| Audio Bandwidth | 200Hz-7.5KHz |
|---|---|
| No. of Full-Duplex Audio Paths | Up to 5 with individual level control |
| Mode of Operation | Full duplex on all routes |
| Level/Talk Controls | 4 pushbuttons, a reply button, and 2 rotary controls |
| Enter/Answer-Back Button | 1 |
| Headset Connector | 7-pin male with PTT |
| Headset Voltage | Maximum of ~+8dBu as set by firmware |
| Microphone Type | Electret and Dynamic, selectable in beltpack menu |
| Modulation | GFSK, TDMA frame 10ms Full and Long slot |
×
×
×
×
