GB6 | GROUNDING BAR FOR TS-1D MODULES

  • MAP: $152.85 / EA
  • List Price: $203.80 / EA
  • Log in to see if custom discounts apply
  • Case Quantity: 0
  • Sign In or Submit RFQ for accurate lead times
GROUNDING BAR FOR TS-1D MODULES
Click image to enlarge

GB6
GROUNDING BAR FOR TS-1D MODULES

  • UM : EA

The TS-1D is intended to protect audio input and output circuits from the effects of transients induced on the audio lines.

Features:

  • Immunity from Electrostatic Discharge
  • Immunity from Induced Transient Voltage
  • Immunity from RF Interference
  • Immunity from Electromagnetic Pulse
  • CE Compliance
AUDIO
Frequency Response 10 Hz to 50 kHz (± 0.25 dB)
Insertion Loss <0.3 dB (into balanced bridging input), <1.0 dB (into 150 Ω or 600 Ω balanced< input), < 6 dB (600 Ω balanced source into 600 Ω load)
ELECTRICAL
Number of Circuits 4, independent (for connection as 4 unbalanced or 2 balanced audio lines)
Equivalent Series Resistance,Input to Output 20 Ω
Equivalent Circuit 300 kHz LP filter, 6 dB/octave, integral shunt high-voltage switch
Maximum Working Signal 30 Vp, 60 V p-p
HV Switch Clamp 24 V actuation
48 V maximum
Transient Energy 0.1 joule
PHYSICAL
Case Material Electromagnetically inert plastic composition
Size 1.75 in. W x 2.5 in. L x 0.9 in. H (4.45 cm x 6.35 cm x 2.29 cm) (including terminal strip)
Ground Bus (integral) 110 alloy copper, 0.25" W x 1.6" L (.64 cm x 4.1 cm) with 2 mounting holes, #6 (.37 cm) clearance, mounting hardware included
Input/Output Termination #6 (.35 cm) captive screw terminals
Package Type Cardboard Box
WEEE weight 0.185 lbs.
Shipping Weight 0.245 lbs.
Tariff code 8543.70.9860
Package Dimensions 2 x 2 x 4 in.
