GTR-PWR-8 | PEDAL BOARD POWER SUPPLY WITH 8 ISOLATED OUTPUTS

  • MAP: $129.99 / EA
  • List Price: $207.99 / EA
  • Log in to see if custom discounts apply
  • Case Quantity: 10
  • Sign In or Submit RFQ for accurate lead times
PEDAL BOARD POWER SUPPLY WITH 8 ISOLATED OUTPUTS
Click image to enlarge

GTR-PWR-8
PEDAL BOARD POWER SUPPLY WITH 8 ISOLATED OUTPUTS

  • UM : EA

·         Outputs: 2 x 4~9V DC @ 120mA, 3 x 9/12V @ 120mA, 1 x 9/18V DC @ 250mA, 1 x 9/12V DC @ 250mA, 1 x 12V AC @ 500mA

·         Maximum Output Current: 1600m

·         AAC Power Input with Switchable Voltage Between 115V/230V (50Hz-60Hz) for International Use

·         Voltage Adjustable via DIP Switch & SAG Knobs (min 4V - max 9V)

·         Heavy-Duty All Metal Enclosure with Slotted Vents for Heat Dissipation

·         Integrated Slots Allow for Direct Mounting to Pedal Board

·         On/Off Power Switch with LED Indicator Light

·         Includes (x1) Power Cable, (x8) DC Power Cables, (x1) AC Power Cable, (x1) Polarity Inverter Cable, (x1) Voltage Doubler Cable, (x1) Mini Jack Cable

·         Product Dimensions: 7.28”/185mm (L) x 4.25”/108mm (W) x 1.93”/49mm (H)

·         Net Weight: 3 lbs./1.36 kg
