INTIMSPOT60ILS | COMPACT 70W MOVING HEAD, ILS COMPATIBLE
INTIMSPOT60ILS
COMPACT 70W MOVING HEAD, ILS COMPATIBLE
INTIMSPOT60ILS
COMPACT 70W MOVING HEAD, ILS COMPATIBLE
- UM : EA
- Estimated Weight: 16.0
Intimidator Spot 60 ILS is a compact, punchy 70-watt moving head for on the go. This fixture is small, but mighty and is ideal for mobile entertainers. The Intimidator Spot 60 ILS is compatible with our ILS* ecosystem of products which means it’s easy to setup and sync to a wide range of fixture types and is D-Fi compatible for wireless control. The ideal counterpart to the Intimidator Free Spot 60 ILS, this fixture has the same impressive feature set including rotating gobos, a 3-facet prism, manual zoom, and automatic focus. As well as features like the new home position, the innovative Totem mode that keeps beams on the dance floor, and a ¼ turn hanging bracket that gets you in and out of your gigs in no time. Enjoy cutting edge ILS technology with the benefits of a compact fixture with the Intimidator Spot 60 ILS.
*Patent Pending
Features:
- Feature-packed moving head designed for mobile performances
- ILS compatibility for use in the ILS ecosystem
- D-Fi USB compatibility for wireless Master/Slave or DMX control (D-Fi USB sold separately)
- New home position allows for smoother programming
- ¼-turn hanging bracket allows for quick removal when needed
- Project crisp gobos from nearly any distance with the motorized focus
- Manual zoom for short or long throw applications
- 3-facet prism splits the beam and covers a larger area
- Beams always remain on the dance floor using the built-in, innovative Totem mode
- Set, save, and recall 1 scene manually, directly from the full-color LCD display
- Link up to 4 fixtures to create eye-catching, synchronized shows in Automated or Sound mode
| DMX Channels | 8, 10 or 14 |
|---|---|
| DMX Connectors | 3-pin XLR |
| Pan and Tilt | 540°/240° |
| Pan and Tilt Ranges | 180°, 360°, 540° pan/90°, 180°, 240° tilt. |
| Colors | 8 + open, split colors, continuous scroll at variable speeds |
| Gobos | 7 + open (6 metal + 1 glass), rotating, interchangeable, slot-n-lock, continuous scroll at variable speeds |
| Light Source | 1 LED (cool white) 70 W, (3.3 A), 50,000 hours life expectancy |
| Strobe Rate | 0 to 20 Hz |
| Zoom Angle | (manual) 15° to 17° |
| Illuminance | (15°) : 10,012 lux @ 2 m(17°) : 7,792 lux @ 2 m |
| Power Linking | 5 units @ 120 V 9 units @ 230 V |
| Input Voltage | 100 to 240 VAC50/60 Hz (auto-ranging) |
| Power and Current | 107 W, 1.5 A @ 120 V, 60 Hz 105 W, 1 A @ 230 V, 50 Hz |
| Gobo Size | 24 mm outside, 20 mm image, 1.1 mm max thickness |
| Weight | 11.2 lb (5.1 kg) |
| Size | 9.9 x 7.8 x 13.8 in (251 x 199 x 351mm) |
| Approvals | CE, RoHS, UKCA |
| Prism | 3-facet round static |
| Optional Controllers | IRC-6 |
| Color Temperature | 15,000 K |
| Bracket Mounting Hole | 13 mm |
