JR2 | UNIVERSAL MOUNT FOR PROJECTORS, LOW PROFILE, 12 ADJUSTMENT POINTS, WEIGHT CAPACTIY 70LB, BLACK
JR2
UNIVERSAL MOUNT FOR PROJECTORS, LOW PROFILE, 12 ADJUSTMENT POINTS, WEIGHT CAPACTIY 70LB, BLACK
JR2
UNIVERSAL MOUNT FOR PROJECTORS, LOW PROFILE, 12 ADJUSTMENT POINTS, WEIGHT CAPACTIY 70LB, BLACK
- UM : EA
- Estimated Weight: 4.0
The Crimson AV JR2 is a universal projector ceiling mount designed for versatility, durability, and low-profile installation. Supporting projectors up to 70 lbs, it features fully adjustable roll (±8°), pitch (±20°), and 360° rotation for precise alignment. Its pre-assembled design and click-in-place quick-release mechanism ensure quick and easy installation on any 1.5" NPT threaded pipe. The JR2 accommodates a maximum mounting pattern of 18.1", offering compatibility with a wide range of projectors. Built from aluminum and high-grade cold-rolled steel with a scratch-resistant finish, it’s available in black (JR2) and white (JR2W). Perfect for integrators and AV professionals, the JR2 combines functionality and sleek aesthetics.
Features:
- Low-profile, holds projector close to ceiling for a subtle appearance
- Completely pre-assembled mounting interface for quick installation
- Fully adjustable roll, pitch and yaw
- 12 total adjustment points; 6 for pitch and 6 for roll
- Quick release mechanism allows for easy service of projector (video projector ceiling mounts)
- Mounts to any 1.5″ NPT threaded pipe
- Pre-sorted hardware pack for easy installation
| Weight capacity | 70lb (31.8kg) |
|---|---|
| Max mounting pattern | 18.1"(460mm) diameter |
| Height | 3.46" (88mm) from ceiling to projector surface |
| Pitch (up/down) | +/- 20° |
| Roll (side to side) | +/- 8° |
| Rotation (yaw) | 360° |
| 1.5" NPT thread compatible | Yes |
| Mounting interface | 1.5" NPT thread compatible |
| Construction | aluminum/high-grade cold rolled steel |
| Product finish | scratch resistant epoxy powder coat |
| Product weight | 2.2lb (1kg) |
| Package specifications | 13"x7"x4" |
| Color | black |
| Warranty | 10-years |
