L 6000 | L 6000 CHARGING STATION, UP TO FOUR MODULES CAN BE FITTED AS NEEDED WITH TWO CHARGING PORTS EACH
L 6000
L 6000 CHARGING STATION, UP TO FOUR MODULES CAN BE FITTED AS NEEDED WITH TWO CHARGING PORTS EACH
L 6000
L 6000 CHARGING STATION, UP TO FOUR MODULES CAN BE FITTED AS NEEDED WITH TWO CHARGING PORTS EACH
- UM : EA
- Estimated Weight: 12.0
Practical, central, intelligent: The 19 inch 1 RU L 6000 charging station delivers power centrally and directly in the rack. Up to four freely selectable charging modules can accommodate two bodypack or handheld battery packs each (a total of 8 charging ports for battery packs BA 60, BA 61 or BA 62). Three-color LEDs give a quick overview of the charging status. The intelligent control system prevents heat buildup and also offers a mode that optimally charges the batteries for extended storage periods.
The charging station L 6000 has a modular construction and is futureproof: Charging stations for future battery pack types can simply be retrofitted.
Extensive details regarding temperature, remaining charging time, run times, charging cycles and battery quality can be retrieved via the Wireless Systems Manager (WSM).
Features:
- 19 inch charging station in 1 RU
- Flexible configurations with loading modules for handheld transmitters or bodypack battery packs (Digital 6000 and Digital 9000)
- Quick overview of charging status with three-color LEDs
- Intelligent charging control with four fans for optimum cooling
- Storage mode keeps battery packs in optimum charge condition for longer storage periods
- Integrates into the Wireless Systems Manager
| Display | Multi-colored |
|---|---|
| Operating relative humidity (≤ %) | Max. 90 % at 40 °C |
| Charging time (h) | BA 60: 80 %: approx. 1:15 h, 100%: approx. 2:30h |
| Power consumption (Amp) | Max. 85 W |
| Charging current (mA) | 2 A |
| Charging voltage (V) | 4.2 V |
| Network protocol | IEEE 802.3-2002 (10/100 Mbit/s), shielded RJ-45 connection |
| Dimensions | 44 x 483 x 373 mm |
| Height (mm) | 175 |
| Length (mm) | 550 |
| Weight (g) | 5.1 kg |
| Width (mm) | 435 |
| Product height | 175 |
| Product weight (g) | 5.1 kg |
| Product width | 435 |
