MAVERICK FORCE X PROFILE
MAVERICKFORCEXPROFILE
MAVERICK FORCE X PROFILE
- UM : EA
- Estimated Weight: 59.0
With superb dimming performance, an expansive 18:1 zoom, and a full armory of features, Maverick Force X Profile is a compact LED moving profile ready for a wide range of short and long throw applications. This fast lightweight powerhouse combines the latest Maverick series technical advancements to achieve 18,963 lumens of output in a design that maintains a flat field of focus all the way from its narrow 3.5° beam to a broad 57.3° spot. Color calibration and gobo selection comes matched to other Force fixtures in the rig, along with an advanced 4-blade shutter frame system and a wheelhouse that includes a variable CMY color mixing system renowned for its real reds, color wheel with CRI and CTB filters, static and rotating gobo wheels, five-facet prism, iris, and frost. Take control with DMX, RDM, sACN, Art-Net, or CRMX.
Features:
- Features a powerful 520W cool white LED engine for intense, crisp projections.
- Delivers a versatile 3.5° to 57.3° zoom range with a flat field of focus.
- Offers a variable CMY system and color wheel with CRI and CTB filters.
- Includes dual gobo wheels, a 5-facet prism, iris, and frost for dynamic effects.
- Ensures flicker-free operation on camera with high-speed PWM and 16-bit dimming.
- Supports DMX, Art-Net, sACN, and CRMX protocols for comprehensive control integration.
| Light Source | 1 LEDs (CW) 520 W, (4.2A), 6966 K, 50,000 hours life expectancy. |
|---|---|
| Color Temperature (at full) | 6966 K |
| Front lens diameters | 145 mm |
| CRI | 72.2 |
| CRI with CRI filter | 90 |
| Beam Angle | 3.4° to 52.2° |
| Field Angle | 3.7° to 55.3° |
| Cutoff Angle | 3.8° to 57.3° |
| Zoom Range | 3.5° to 57.3° |
| Lumens – Output | 18,963 |
| Illuminance (3.4°) | 104,429 lux @ 5 m |
| Illuminance (57.3°) | 1,219 lux @ 5 m |
| Selectable PWM | 600Hz, 1500Hz, 2000Hz 65000Hz |
| Power Connection | Edison plug to Seetronic Powerkon IP65 |
| Power Input | Seetronic Powerkon IP65 |
| Power Output | Seetronic Powerkon IP65 |
| Data Connectors | 3- and 5-pin IP65 XLR, Seetronic etherCON |
| Cable Length (power) | 5 ft (1.5 m) |
| Control Protocol | DMX, Art-Net, sACN, CRMX, NFC |
| DMX Channels | 31 or 47 |
| Art-Net Channels | 31 or 47 |
| Modes/Personalities | 2 personalities (31, 47) |
| Certifications | CE, MET, FCC, FCC, UKCA |
| IP Rating | IP20, dry location |
| Temperature (Ambient) | -4 °F to 113 °F (-20 °C to 45 °C) |
