MAVERICKSTORM3PROFILE | MAVERICK STORM 3 PROFILE
MAVERICKSTORM3PROFILE
MAVERICK STORM 3 PROFILE
MAVERICKSTORM3PROFILE
MAVERICK STORM 3 PROFILE
- UM : EA
- Estimated Weight: 83.0
With an 18:1 zoom and a full armory of features, Maverick Storm 3 Profile is a compact IP65 moving profile with incredible reach. This lightweight powerhouse combines the latest Maverick series technical achievements with the durability and versatility to perform indoors and out. Harness over 30,000 lumens of output as you go from a narrow 3.4° beam to a wide 56.7° spot. Freely create with its exquisitely sharp framing shutter system and a wheelhouse that includes variable CMY + CTO color mixing, color wheel with CRI and CTB filters, static and rotating gobo wheels, five-facet prism, iris, and frost. This Maverick weathers the storm and welcomes the sunshine with SunShield technology that comes on with complete protection of all internal optical components whenever the fixture powers down
Features:
- Delivers over 30,000 lumens from a powerful 620W 7500K LED engine.
- Features a four-blade framing system with full rotational capability for precise beam shaping.
- Includes a color wheel with dedicated CRI and CTB filters for enhanced color rendering.
- Offers dual gobo wheels, a 5-facet prism, iris, and frost for layered visual effects.
- Integrated SunShield technology protects internal optics from sun damage when the fixture is idle.
- Supports DMX, WDMX, sACN, and Art-Net protocols for flexible system integration.
| Light Source | 1 LEDs (CW) 588 W, (4.6 A), 7500 K, 50,000 hours life expectancy |
|---|---|
| Color Temperature (at full) | 7,242 K |
| CRI | 71.4 |
| CRI with CRI Filter | 90.3 |
| Front Lens Diameter | 127 mm |
| Beam Angle | 6° to 42° |
| Field Angle | 7.1° to 54.1° |
| Cutoff Angle | 7.7° to 56.5° |
| Zoom Range | 6° to 54.1° |
| Lumens – Source | 43,500 |
| Lumens – Output | 25,840 |
| Selectable PWM | 600 Hz, 1,200 Hz, 4,000 Hz, 6,000 Hz, 15,000 Hz |
| Power Connection | Termination-ready bare-ended |
| Power Input | proprietary IP65 |
| Data Connection | bare wired to proprietary IP65 input cable |
| Data input/output | Termination-ready bare-ended |
| Control Protocol | Art-Net, DMX, RDM, W-DMX, sACN |
| DMX Channels | 32 or 48 |
| Art-Net Channels | 32 or 48 |
| Modes/Personalities | 2 personalities (32, 48) |
| Certifications | CE, MET, FCC |
| IP Rating | IP66, temporary outdoor/wet use, with pressure equalizing M12 GORE valve |
| Temperature (Ambient) | 4 °F to 113 °F (-20 °C to 45 °C) |
