OS62-W | 60° X 20° OUTDOOR SPEAKER 1.4”/1.0” COAXIAL COMPRESSION DRIVER - WHITE

The OS62-W is a three-way loudspeaker featuring a Neodymium ring-radiator coaxial compression driver for mid and high frequencies, with a 1.4” exit and 4.0” voice coil for mids, and a 1.0” exit and 2.5” voice coil for highs, integrated with Paraline Technology. Low frequencies are produced by four 8" Neodymium high-output transducers sharing the same horn as the mid and high drivers. The loudspeaker employs a compact Synergy Horn design that provides a uniform coverage pattern of 60° horizontal by 20° vertical.

The OS62-W operates through a single amplifier channel using Synergy crossovers that maintain phase alignment across frequency bands to reduce off-axis distortion. It includes Sentinel protection circuitry for the high-frequency driver with a multistage limiter to prevent overload damage without affecting dynamic range. The enclosure is constructed from thermo-molded poly-composite, equipped with a two-stage stainless steel baffle and hydrophobic screen, rated IP55. An aluminum mounting bracket and angle strap are supplied for secure mounting in indoor and outdoor environments.
