PD743I-WRX | VERY HIGH OUTPUT MID-HIGH LOUDSPEAKER SYSTEM, EXTREME WEATHER PROTECTION SYSTEM

  • Call for Price
  • Log in to see if custom discounts apply
  • Case Quantity: 1
  • Sign In or Submit RFQ for accurate lead times
VERY HIGH OUTPUT MID-HIGH LOUDSPEAKER SYSTEM, EXTREME WEATHER PROTECTION SYSTEM
Click image to enlarge

PD743I-WRX
VERY HIGH OUTPUT MID-HIGH LOUDSPEAKER SYSTEM, EXTREME WEATHER PROTECTION SYSTEM

  • UM : EA

The PD743I-WRX is a dual 8-inch, 2-way horn-loaded loudspeaker featuring a 40° x 30° horn for directional sound projection. It delivers continuous sound pressure levels exceeding 104 dB SPL at distances up to 50 meters (165 feet). The design facilitates long-throw sound reinforcement beyond the capabilities of standard single-driver systems.

Features:

  • 40° by 30° coverage pattern
  • IFS Interference Free Summation dual HF driver module
  • Dual 2432H compression drivers with 3” diaphragms
  • Dual CMCD-82H 8” horn loaded cone mid-range drivers
  • Pattern control maintained below 400 Hz
  • Co-axial mid/high-frequency module layout
  • Integrated rigging system
Frequency Range 200 Hz to 19.5 kHz
Frequency Response 230 Hz to 18.5 kHz
Coverage Pattern 40° x 30°
Directivity Index 16 dB
System Sensitivity 110 dB SPL (1W @ 1m)
Maximum Peak SPL 142 dB Peak Passive Mode
Transducer Power Rating 400 W (1600 W Peak)
Crossover Frequency 1.2 kHz
DSP Custom DSP for Crown ITHD and IT4x3500HD amplifiers
Nominal Impedance MF 4ohms, HF 16ohms
