RW5757US | FX16II MIXER - 16 INPUTS, 16 MONO MIC CHANNELS, 4 STEREO RETURNS, 32 FX SETTINGS
RW5757US
FX16II MIXER - 16 INPUTS, 16 MONO MIC CHANNELS, 4 STEREO RETURNS, 32 FX SETTINGS
RW5757US
FX16II MIXER - 16 INPUTS, 16 MONO MIC CHANNELS, 4 STEREO RETURNS, 32 FX SETTINGS
- UM : EA
- Estimated Weight: 38.1
The
Soundcraft FX16ii offers a combination of powerful live and recording features;
each channel has a Direct Output which is individually switch-able pre or post
fader to enable use with 16-track recording systems.
Specifications:
· 26 inputs
· 16 mono microphone channels.
· 4 stereo returns
· 4-bus architecture, with sub-group routable to mix
· Built-in 24 bit Lexicon digital effects processor
· 32 FX settings
· Tap Tempo
· 3 FX parameter adjust rotaries
· User FX settings store function
· Direct outputs for multi-track recording individually
switch-able for pre-post-fade operation
· Inserts on all mono channels
· Inserts on stereo mix output
· Classic Soundcraft 3-band EQ with swept mid-band
· Stereo 18dB/octave 100Hz high-pass filter
· Dual global +48V phantom power split channels 1-8 and
9-16
· Channel Mute control
· 10-segment tri-colored metering
· Two sub-group outputs
· Separate mono sum output
· Integral universal power supply
