SCORPIONDUALRGBILS | 32 BUILT-IN PATTERNS, ILS COMPATIBLE, D-FI USB COMPATIBILITY
SCORPIONDUALRGBILS
32 BUILT-IN PATTERNS, ILS COMPATIBLE, D-FI USB COMPATIBILITY
SCORPIONDUALRGBILS
32 BUILT-IN PATTERNS, ILS COMPATIBLE, D-FI USB COMPATIBILITY
- UM : EA
- Estimated Weight: 22.0
Let your lighting creativity run wild with Scorpion Dual RGB ILS, a Dual RGB FAT BEAM™ aerial effect laser that generates customized and ever-changing laser shows using programmable pan, tilt, and zoom effects with separate X, Y, and Z rolling effects and scan speed adjustment. This laser features 32 built-in patterns, including the popular “Laser Sky” effect offers perfect color combinations by mixing red, green, and blue laser diodes. Its unique dual mirror output makes a great centerpiece or side accent in pairs. Scorpion Dual RGB ILS features compatibility with ILS which makes creating coordinated light shows across different fixture types easy. D-Fi™ USB compatibility is also on board for wireless Master/Slave or DMX control. Scorpion Dual RGB ILS is fully FDA compliant, variance-free, and ready to use right out of the box. Easily operate Scorpion Dual RGB ILS in automatic, Master/Slave, manual or sound-activated mode. Wireless control is also possible using the optional IRC-6 remote.
Features:
- Dual RGB FAT BEAM aerial effect laser, perfect for events with fog or haze
- D-Fi USB compatibility for wireless Master/Slave or DMX control (D-Fi USB sold separately)
- Create perfect color combinations by mixing red, green, and blue laser diodes
- Unique dual mirror output that makes a great centerpiece or side accent in pairs
- 32 built-in patterns, including the popular “Laser Sky” effect
- Wireless control using the optional IRC-6 remote
- Generate customized and ever-changing laser shows using programmable pan, tilt, and zoom effects with separate X, Y, and Z rolling effects and scan speed adjustment
- Fully FDA compliant, variance-free and ready to use right out of the box
- Easily operate in automatic, Master/Slave, manual or sound-activated mode
- Fits best in the CHS-40 VIP Gear Bag
| Dmx channels: | 10 |
|---|---|
| Dmx connectors: | 3-pin XLR |
| Pan and tilt: | 30°/30° |
| Light source: | 638 nm/30mW (red) laser diode, 520 nm/20 mW (green) laser diode, 450 nm/ 50 mW (blue) laser diode |
| Strobe rate: | 0 to 27 Hz |
| Zoom angle: | 1° to 29° |
| Coverage angle: | 36° |
| Power linking: | 27 units @ 120 V 48 units @ 230 V |
| Input voltage: | 100 to 240 VAC, 50/60 Hz (auto-ranging) |
| Power and current: | 20 W, 0.3 A @ 120 V, 60 Hz 19 W, 0.2 A @ 230 V, 50 Hz |
| Weight: | 3.8 lb (1.7 kg) |
| Size: | 8.5 x 7 x 6.3 in (216 x 179.5 x 161 mm) |
| Approvals: | CE, FDA |
| Bracket mounting hole: | M12 |
| Ambient operating temperature: | 59 °F to 95 °F (15 °C to 35 °C) |
| Optional controllers: | IRC-6 |
