SH96HO-I-EDM | 90 X 60 DEGREE SPEAKER, BI-AMP ONLY INSTALL VERSION

  • Call for Price
  • Log in to see if custom discounts apply
  • Case Quantity: 0
  • Sign In or Submit RFQ for accurate lead times
90 X 60 DEGREE SPEAKER, BI-AMP ONLY INSTALL VERSION
Click image to enlarge

SH96HO-I-EDM
90 X 60 DEGREE SPEAKER, BI-AMP ONLY INSTALL VERSION

  • UM : EA

The SH96HO-I-EDM loudspeaker features a configuration of 11 drivers integrated into a single Synergy Horn measuring 45 inches by 26 inches. The driver array includes four 15-inch low-frequency drivers, six 4-inch mid-range drivers, and one 1.4-inch high-frequency exit compression driver.

The drivers are mounted within the horn and connected through a Synergy crossover network designed to achieve phase alignment across frequency bands. This configuration minimizes off-axis frequency response distortions by synchronizing the output of the separate driver groups as they combine within the horn.

Coverage Pattern 90° horizontal
Operating Frequency Range 45 Hz – 13.5 kHz ± 3 dB
Continuous Output 133 dB SPL
Peak Output 139 dB SPL
Sensitivity 105 dB SPL
Driver Complement 4 x 15" low
Rated Impedance low
Power Rating low
