SM96-I | 90 X 60 DEGREE, 2 X 8" LF, 5"/1" COAXIAL SPEAKER (INSTALLATION VERSION)

  • Call for Price
  • Log in to see if custom discounts apply
  • Case Quantity: 0
  • Sign In or Submit RFQ for accurate lead times
90 X 60 DEGREE, 2 X 8" LF, 5"/1" COAXIAL SPEAKER (INSTALLATION VERSION)
90 X 60 DEGREE, 2 X 8" LF, 5"/1" COAXIAL SPEAKER (INSTALLATION VERSION)
90 X 60 DEGREE, 2 X 8" LF, 5"/1" COAXIAL SPEAKER (INSTALLATION VERSION)
Click image to enlarge
90 X 60 DEGREE, 2 X 8" LF, 5"/1" COAXIAL SPEAKER (INSTALLATION VERSION)
90 X 60 DEGREE, 2 X 8" LF, 5"/1" COAXIAL SPEAKER (INSTALLATION VERSION)
90 X 60 DEGREE, 2 X 8" LF, 5"/1" COAXIAL SPEAKER (INSTALLATION VERSION)

SM96-I
90 X 60 DEGREE, 2 X 8" LF, 5"/1" COAXIAL SPEAKER (INSTALLATION VERSION)

  • UM : EA
  • Estimated Weight: 79.2

This speaker offers crystal clear 90-degree x 60-degree coverage in a compact box and has the added benefit of truly modular array-ability. The SM96 combines great fidelity, low frequency pattern control and unrivaled magnitude/phase response into an ultra-compact enclosure. The SM96 is available for installation or for touring.



Coverage Pattern

90° horizontal, 60° vertical

Operating Frequency Range

55Hz-24KHz +/-3dB,
42Hz-26KHz-10dB

Continuous Output

124 dB SPL

Peak Output

130 dB SPL

Sensitivity

98 dB SPL (2.83V into rated Z, at 1 meter) measured in free space

Magnitude Response

55Hz-24KHz

Driver Complement

Low 2 x 8",
High 1 x 5"

Dimensions

31.5 x 21 x 15.5 inches

Weight

73 lbs

Rated Impedance

4 Ohms

Power Rating

800W continuous,
3,200W peak
