SRA-4075 | POWER AMPLIFIER 4 X 75W @ 4 OHMS, CONVECTION COOLED SRA SERIES
SRA-4075
POWER AMPLIFIER 4 X 75W @ 4 OHMS, CONVECTION COOLED SRA SERIES
SRA-4075
POWER AMPLIFIER 4 X 75W @ 4 OHMS, CONVECTION COOLED SRA SERIES
- UM : EA
- Estimated Weight: 13.0
SRA Convection-Cooled Amplifiers are advanced, efficient single-space amplifiers perfect for installations with modest power requirements. The SRA Series makes it a snap to get exactly what you need and nothing you don’t. Housed in compact single rack space chassis and weighing only 10 lbs, SRA Convection-Cooled Amplifiers are designed to drive 4 or 8-ohm loads. Choose from 4 models available in 2 and 4-channel configurations with power ratings of 75W and 150W per channel.
The 150W models are capable of driving 25V constant voltage lines directly. Switch mode power supplies and Class-D amplifier circuitry provide an extremely power efficient solution.
|
Model |
Channels |
Watts @ 4O |
Watts @ 8O |
Watts @ 8O Bridged |
Constant Voltage |
|
SRA-2075 |
2 |
75 |
40 |
150 |
— |
|
SRA-2150 |
2 |
150 |
80 |
300 |
yes |
|
SRA-4075 |
4 |
75 |
40 |
150 |
— |
|
SRA-4150 |
4 |
150 |
80 |
300 |
yes |
FEATURES
- Extremely low noise, convection cooled
- Extensive protection circuitry including output overcurrent protection, DC output protection, main supply rail overvoltage protection, internal chassis temperature monitoring, in-rush limiting and mains fuse
- Level attenuators with level control
- Signal present and clip alert status LEDs
- 2-channel versions have a stereo headphone jack
- Selectable input sensitivity
- 80 Hz/ Off High Pass Filter
- Rear panel Gain Switch: +36 dB or +26dB input sensitivity
- Euroblock inputs/outputs
- Normal or bridged mode switch on each channel
- Remote power turn ON/OFF
- Adjustable turn-on delay up to 7.5 seconds
- Safety/Compliance: TUV, CE, FCC, RoHS
- 5-Year Warranty
