VRX928LA | 8" 2-WAY LINE-ARRAY SYSTEM WITH 1 X 2168H-1 DIFFERENTIAL DRIVE 400 W LF; 2 X 2414H

  • MAP: $1,799.00 / EA
  • List Price: $2,660.00 / EA
  • Log in to see if custom discounts apply
  • Case Quantity: 1
  • Sign In or Submit RFQ for accurate lead times
8" 2-WAY LINE-ARRAY SYSTEM WITH 1 X 2168H-1 DIFFERENTIAL DRIVE 400 W LF; 2 X 2414H
8" 2-WAY LINE-ARRAY SYSTEM WITH 1 X 2168H-1 DIFFERENTIAL DRIVE 400 W LF; 2 X 2414H
Click image to enlarge
8" 2-WAY LINE-ARRAY SYSTEM WITH 1 X 2168H-1 DIFFERENTIAL DRIVE 400 W LF; 2 X 2414H
8" 2-WAY LINE-ARRAY SYSTEM WITH 1 X 2168H-1 DIFFERENTIAL DRIVE 400 W LF; 2 X 2414H

VRX928LA
8" 2-WAY LINE-ARRAY SYSTEM WITH 1 X 2168H-1 DIFFERENTIAL DRIVE 400 W LF; 2 X 2414H

  • UM : EA

The VRX928LA is a lightweight (28 lb / 13 kg) compact 8" two-way linearray speaker system designed for use in arrays of up to six units.

Features:

  • Constant Curvature Array - The waveguide mounts two compression drivers on a continuous arc enabling them to work together acoustically as if they were a single driver.
  • Amplitude Shading- Convenient series of switches on each enclosures that controls the output of each high frequency section in the array.
  • Suspension and Rigging.
  • Dual Angle Pole Socket - JBL''s dual angle pole sockets allow great flexibility in aiming the enclosure (not on - WH version)
  • Differential Drive Woofer.
Power Rating 400 W / 800 W / 1600W
Frequency Range (-10dB) 70 Hz - 20 kHz
Dimensions (H x W x D) 230mm x 420mm x 270mm (9.0in x 16.5in x 10.5in)
Coverage Pattern 100 x 15 nominal
Frequency Response (±3 dB) 85 Hz - 19 Hz
Crossover Modes Bi-amp / passive,
Crossover Frequency 2.0 kHz
Net Weight (each) 12.7 kg (28 lb)
Inputs Neutrik Speakon NL-4 (x2)
Outputs 1 x XLR
Enclosure Duraflex coated plywood
System Type Constant Curvature 8" Two-Way Line Array System
Maximum SPL (1m) 122 dB SPL peak (passive mode)LF: 122 dB (bi-amp mode)HF: 128 dB (bi-amp mode)
Nominal Impedance Passive = 8 ohmBi-amp LF = 8 ohmBi-amp HF = 16 ohm
LF Driver 1 x 200 mm (8 in) Differential Drive woofer
HF Driver 2 x 25 mm (1.0 in) neodymium compression driver
Suspension / Mounting Dual 36 mm pole socket included. Suspension requires optional VRX-SMAF line array frame kit or M10 eyebolts.
