VW4600G3 | VIDEO WALL MOUNT WITH PUSH IN, POP OUT TECHNOLOGY AND 6 POINTS OF ADJUSTMENT FOR EASY ALIGNMENT
VW4600G3
VIDEO WALL MOUNT WITH PUSH IN, POP OUT TECHNOLOGY AND 6 POINTS OF ADJUSTMENT FOR EASY ALIGNMENT
VW4600G3
VIDEO WALL MOUNT WITH PUSH IN, POP OUT TECHNOLOGY AND 6 POINTS OF ADJUSTMENT FOR EASY ALIGNMENT
- UM : EA
- Estimated Weight: 23.0
In addition to vertical, horizontal, and plumb adjustments, the VW4600G3 allows for nearly 3” of depth micro-adjustment for ultimate ease in video wall alignment especially in instances where walls are uneven. Up to 11.00” of pull-out extension with quick release mechanisms allow for quick and simple access to wiring and monitor servicing, and an integrated lock and key system ensures safety and security. Crimson''s proprietary Push in-Pop out Technology allows a single display to be accessed without any disruption to the rest of the matrix, and the entire grid can be laid out by a single installer.
Features:
- Full featured video wall solution and pull out mount
- Up to 3″ of depth adjustment to address uneven walls
- 11.00″ pull out extension from wall for easy wiring
- Push in-Pop out Technology to access middle displays of matrix
- Lateral shift
- Vertical adjustment and leveling
- Plumb adjustment
- Integrated dual keyed lock system
| TV size range | 37” – 75” |
|---|---|
| Weight capacity | 150lb (68kg) |
| Max mounting pattern | 783x402mm |
| VESA mounting patterns | 200x200mm, 300x200mm, 300x300mm, 400x200mm, 400x300mm, 400x400mm, 600x200mm, 600x400mm |
| Depth from wall | 3.85” min (98mm) to 6.80" (173mm) max |
| Max Extension | 11.00" |
| Lateral adjustment | varies with screen |
| Mounting surface | stud, concrete, cinder block or metal stud (accessory required HT4) |
| Construction | high-grade cold rolled steel |
| Product finish | scratch resistant epoxy powder coat |
| Product weight | 22 lbs |
| Package specifications | 35.5" x 12.75 " 4.75" |
| Color | black |
| Warranty | Lifetime |
