FREEDOMPARQ9 | TRUE WIRELESS, BATTERY-OPERATED, QUAD-COLOR (RGBA) LED
FREEDOMPARQ9
TRUE WIRELESS, BATTERY-OPERATED, QUAD-COLOR (RGBA) LED
FREEDOMPARQ9
TRUE WIRELESS, BATTERY-OPERATED, QUAD-COLOR (RGBA) LED
- UM : EA
- Estimated Weight: 20.9
Experience the next generation of 100% TRUE wireless, battery-operated event lighting power with Freedom Par Q9. This quad-color (RGBA) LED uplight not only has the favorite built-in D-Fi transceiver for wireless DMX control, but even more wireless options are available with a built-in RF receiver for use with the RFC or RFC-XL optional remotes. Brilliant color mixing comes from new secondary optics and a magnetic diffuser pops on or off with ease to widen the coverage area. Adjusting settings has never been easier with the OLED display with full-text and now you can adjust run times to keep the Freedom power going all event long!
Features:
- 100% TRUE wireless, battery-operated, quad-color (RGBA) LED uplight with built-in D-Fi transceiver
- New secondary optics provide perfect color blending with nearly no artifacts
- Magnetic diffuser pops on or off with ease and widens the coverage area
- Adjustable run times ensure the fixture will last the length of the event
- OLED display allows for full-text and to easily change fixture’s settings
- Built-in RF receiver for wireless control using the RFC or RFC-XL optional remotes
- Adjust the projection angle using the spring-loaded kickstand
- Built-in glare shield protects light spillage and eye fatigue
- Extend the fixture’s lifespan with the onboard charge and discharge protection circuitry
- Achieve smooth LED fading with built-in dimming curves
- Compact and lightweight design easily fits inside sticks of TRUSST
| DMX Channels | 4, 6 or 14 |
|---|---|
| Max Unobstructed Distance | 600 ft (183 m) |
| Light Source | 9 LEDs (quad-color RGBA) 6 W, (2.3A), 50,000 hours life expectancy |
| Strobe Rate | 0 to 22 Hz |
| Beam Angle | 19° |
| Field Angle | 35° |
| Recharge Time | 3 hours |
| Operating Frequency | 2.412 to 2.484 GHz |
| Illuminance | 3580 lux @ 2 m |
| Lumens | 1,161 |
| Input Voltage | 24 VDC, 1.5 A (external power supply: 24 VDC, 50/60 Hz) |
| Power and Current | 31 W, 0.3 A @ 120 V, 60 Hz30 W, 0.2 A @ 230 V, 50 Hz |
| Weight | 4.6 lbs (2.1 kg) |
| Size | 4.7 x 4.7 x 4.9 in (120 x 120 x 126 mm) |
| Approvals | CE, UKCA, RoHS, FCC |
| Beam Angle (with diffuser) | 37° |
| Field Angle (with diffuser) | 68° |
| Illuminance (with diffuser) | 529 lux @ 2 m |
| Lumens | 1,161 |
| Run Time (adjustable) | 3, 5, 8, or 12 hrs |
| Mounting Hole | M12 |
| Optional Controllers | RFC, RFC-XL, FlareCON |
