CONTROL 419CS/T
8" CEILING SUBWOOFER

  • UM : EA

The CONTROL 419CS/T is a ceiling-mounted subwoofer featuring an 8-inch (200 mm) woofer and an integrated enclosure designed for installation in standard ceiling plenum spaces. It includes a built-in passive low-pass filter for integration with Control 400 Series full-range speakers.

Features:

  • 8-inch woofer
  • Integrated enclosure with tapered ports for smooth bass
  • Built-in passive low-pass filter
  • Built-in 70V/100V multi-tap transformer and 8-ohm input
  • Magnetic paintable baffle
  • Top and side cable exit options
  • Adjustable dogears for ceiling thickness
  • IP33 rated
Frequency Range 47 Hz – 320 Hz
Power Capacity 320 W Continuous Program (2 hrs), 160 W Continuous IEC Pink Noise (2 hrs), 80 W Continuous IEC Pink Noise Power (100 hrs)
Sensitivity 89 dB, 96 dB near corner, 93 dB near wall, 90 dB at 1 W @ 1 m
Coverage Angle 180° conical
Maximum SPL (1m) 124 dB peak, 118 dB continuous (2 hrs)
Nominal Impedance 8ohms
Transformer Taps 70 V - 60 W, 30 W, 15 W, 7.5 W; 100 V - 60 W, 30 W, 15 W
LF Driver 200 mm (8 in)
HF Driver n/a
Safety Agency Rating UL1480A, UL2043, NFPA90, NFPA70, S7232/UL Listing, CSA C22.2 no. 205, IEC60849/EN60849 compliant
Environmental Exceeds Mil Spec 810H; IP33 rating per EN/IEC 60529; RoHS2 compliant; Operating temperature 0°C to 45°C
Color Stock baffle white (RAL9003), paintable
