LSR310S | 10" POWERED STUDIO SUBWOOFER WITH XLF EXTENDED LOW FREQUENCY SETTING
LSR310S
10" POWERED STUDIO SUBWOOFER WITH XLF EXTENDED LOW FREQUENCY SETTING
Click image to enlarge
LSR310S
10" POWERED STUDIO SUBWOOFER WITH XLF EXTENDED LOW FREQUENCY SETTING
- UM : EA
The LSR310S is a powered studio subwoofer featuring a custom 10-inch down-firing driver and a 200-watt amplifier. It incorporates JBL’s patented Slip Stream port design to enhance low-frequency performance. The subwoofer includes an XLF (Extended Low Frequency) setting, which extends bass response for applications requiring augmented low-frequency tuning.
Designed for integration with studio monitor systems, the LSR310S provides precise low-frequency extension to support audio mixing and monitoring tasks.
Features:
- JBL Patented Slip Stream Port for deep, dynamic bass
- XLF Extended Low Frequency Setting for dance club bass tuning
- Custom 10" Down-Firing High Excursion Low Frequency Driver
- Professional Balanced Inputs and Outputs with XLR and 1/4" connectors
- Selectable Input Sensitivity (-10dBV/+4 dBu)
- Three Crossover Settings (80 Hz, External)
- Detented Volume Control for easy balancing
LF Driver | 250mm High-Excursion, Down-Firing |
---|---|
Low Frequency Extension | 27 Hz |
Maximum Peak SPL | 113 dB |
Amplifier Power Rating | 200 W Class D |
Crossover Settings | 80 Hz, XLF, External |
Input Connectors | 2 x XLR, 2 x TRS Balanced |
Outputs | 2 x XLR |
Maximum Peak Input Level | +20.3 dBu |
AC Voltage | 100-240 VAC +/- 10% 50/60 Hz |
LF Driver Power Handling | 200 W Class D |
