ALF-VMIX41 | MULTIFUNCTIONAL, PROFESSIONAL QUAD HDMI VIDEO SWITCHER W/ 4X HDMI INPUT PORTS
ALF-VMIX41
MULTIFUNCTIONAL, PROFESSIONAL QUAD HDMI VIDEO SWITCHER W/ 4X HDMI INPUT PORTS
ALF-VMIX41
MULTIFUNCTIONAL, PROFESSIONAL QUAD HDMI VIDEO SWITCHER W/ 4X HDMI INPUT PORTS
- UM : EA
- Estimated Weight: 9.0
The Alfatron VM-41 is a 4x1 HDMI video switcher, designed to seamlessly switch between four HDMI inputs to a single output. Supporting 4K@60Hz resolution with HDR and HDCP 2.2 compliance, this high-performance switcher ensures crisp, high-definition video quality for professional AV applications. The VM-41 features auto-switching, front-panel control, IR remote control, and RS-232 integration, making it an ideal solution for conference rooms, classrooms, home theaters, and digital signage setups. Its plug-and-play design and seamless signal switching provide effortless operation for AV integrators and installers looking for a reliable and compact HDMI switcher.
|
Video Source |
HDMI IN x 4 |
|
Video Output |
PGM x 2 UVC x 1 |
|
Audio Input |
MIC/Line level(3.5mm stereos)x2 |
|
USB |
USB x 1 |
|
Lan |
LAN x 1 |
|
Power |
DC 7~12V =12W |
|
Function |
|
|
Switching |
T-Bar/AUTO/ CUT |
|
Effects |
WIPE/MIX/DIP/PAT/STILL/MUTE/FTB |
|
Layout |
Multi Layout format(see 5.4.3) |
|
Keying |
Luma Key?Chroma Key |
|
Audio Sources |
HDMI x 4 and MIC/ Line level x 2; |
|
Audio Delay |
0-5s |
|
Media |
Importable pictures and logos |
|
Video format |
|
|
HDMI Input |
1080p 60/59.94/50/30/29.97/25/24/23.98 1080i50/1080i60 720p 60/59.94/50/30/29.97/25/24/23.98 576i/480i/576p/480p |
|
HDMI PGM output |
1080p 60/50/30/25/24 1080i50/1080i60 |
|
HDMI color format |
RGB/YUV |
|
USB streaming |
max 1080p60 |
|
Stream media |
H.264 encoder, supports video recording and 2 network streaming, with adjustable code rate |
|
Others |
|
|
Power Supply |
7~24V |
|
Size (LWD) |
354*165*121mm |
|
Weight |
2kg |
|
Temperature |
Working: 0?~50?, Storage: -30?~70? |
|
Accessory |
Transformer(12V 2A)x1; |
