C55V | CEILING MOUNT BOX AND VESA SCREEN ADAPTER ASSEMBLY FOR 32IN TO 55IN+ SCREENS
C55V
CEILING MOUNT BOX AND VESA SCREEN ADAPTER ASSEMBLY FOR 32IN TO 55IN+ SCREENS
C55V
CEILING MOUNT BOX AND VESA SCREEN ADAPTER ASSEMBLY FOR 32IN TO 55IN+ SCREENS
- UM : EA
- Estimated Weight: 19.2
Attaches to standard 1.5″ threaded extension columns. Can be used as retrofit on existing columns or combine with Crimson E-series fixed extensions or EA-series adjustable extensions and CA ceiling adapters to complete the solution. Continuous tilt of 15° forward with 360° rotation. Makes a secure screen installation quick and easy, simply hang the screen and turn the pre-assembled securing screw to lock the universal adapter in place. Compatible with all 1.5″ NPT threaded pipe.
Features:
- VESA compatible
- Fast and easy installation
- Landscape or portrait orientation
- Up to 15° of continuous tilt and 360° rotation
- Post installation screen leveling without use of tools
- Mounts to any 1.5″ NPT threaded pipe
- Pre-sorted hardware pack for easy installation
| TV size range | 32" – 55"+ |
|---|---|
| Weight capacity | 100lb (45kg) |
| Max mounting pattern | 400x400mm |
| VESA mounting patterns | 100x100mm, 200x100mm, 200x200mm, 300x200mm, 300x300mm, 400x200mm, 400x300mm, 400x400mm |
| Tilt | +15°/-5° |
| Roll (side to side) | 6° tool less screen leveling |
| Rotation (yaw) | 360° |
| 1.5" NPT thread compatible | Yes |
| Mounting interface | 1.5" NPT thread compatible |
| Construction | high-grade cold rolled steel |
| Product finish | scratch resistant epoxy powder coat |
| Product weight | 14.8lb (6.7kg) |
| Package specifications | 21"x13"x9" |
| Color | black |
| Warranty | 10-years |
