F55 | UNIVERSAL FLAT WALL MOUNT FOR 32IN TO 75IN+ FLAT PANEL SCREENS
F55
UNIVERSAL FLAT WALL MOUNT FOR 32IN TO 75IN+ FLAT PANEL SCREENS
Click image to enlarge
F55
UNIVERSAL FLAT WALL MOUNT FOR 32IN TO 75IN+ FLAT PANEL SCREENS
- UM : EA
- Estimated Weight: 6.8
Adjustable flat wall mount with Universal hole pattern to fit a wide selection of flat panel screens. Makes a secure installation quick and easy, simply hang the screen and turn the pre-assembled securing screw to lock in place. Open wall plate design and kickstand feature provides easy access to wiring.
Features:
- Universal design
- VESA compatible
- Low-profile, holds screen close to wall for a clean look
- Open wall plate allows easy access for wiring
- Lateral shift for perfect placement
- Pre-sorted hardware pack for easy installation to wood studs or concrete surfaces included
| TV size range | 32" – 75" |
|---|---|
| Weight capacity | 200lb (91kg) |
| Max mounting pattern | 660x501mm |
| VESA mounting pattern | 75x75mm, 100x100mm, 200x100mm, 200x200mm, 300x200mm, 300x300mm, 400x200mm, 400x300mm, 400x400mm, 600x200mm, 600x400mm, 600x500mm |
| Depth from wall | 1.2" (30mm) |
| Lateral adjustment | varies with screen |
| Mounting surface | wood stud, concrete, cinder block or metal stud (accessory required HT4) |
| Stud spacing | dual stud 16", 20", 24" on center |
| Construction | high-grade cold rolled steel |
| Product finish | scratch resistant epoxy powder coat |
| Product weight | 3.3lb (1.5kg) |
| Package specifications | 29"x11"x4" |
| Color | black |
| Warranty | 10-years |
×
×
