OVATIONH265WWBLK | OVATION H-265WW SILENT, CONVECTION COOLED LED HOUSE LIGHT WITH A POWERFUL WARM WHITE LIGHT
OVATIONH265WWBLK
OVATION H-265WW SILENT, CONVECTION COOLED LED HOUSE LIGHT WITH A POWERFUL WARM WHITE LIGHT
OVATIONH265WWBLK
OVATION H-265WW SILENT, CONVECTION COOLED LED HOUSE LIGHT WITH A POWERFUL WARM WHITE LIGHT
- UM : EA
- Estimated Weight: 21.0
Ovation H-265WW is a silent, convection cooled LED houselight with a powerful warm white light output and a high CRI, ideal for theatres, worship venues and recital halls or any other application where silent operation is crucial. The unit also features 16-bit dimming, RDM and W-DMX control as well as adjustable PWM to prevent flickering on televised performances. Interchangeable lenses for height adjustment are another indispensable feature in theatrical and house of worship applications. For even more versatility, the yoke can be completely removed, and the fixture suspended, pendant style, from a loop on the back plate. White housing not available in European Markets.
Features:
- Features a 230 W LED source with an exceptional 97 CRI for superior color rendering.
- Operates in complete silence with a fanless, convection-cooled design for sensitive environments.
- Interchangeable lenses adapt the beam angle for various mounting heights and venue sizes.
- Offers versatile mounting with a removable yoke or a direct-to-pipe pendant-style option.
- Supports DMX, W-DMX, and RDM protocols for comprehensive and flexible control integration.
- Adjustable PWM ensures flicker-free performance for broadcast and recording applications.
| light source | 1 LEDs (WW) 230 W, (2.3 A), 3258 K, 50,000 hours life expectancy |
|---|---|
| color temperature (at full) | 3258 K |
| cri | 97 |
| beam angle | (W/80° Filter) 40° (W/65°) 50° (W/45° Lens) 39° (W/25° Lens) 19° |
| beam angle | (W/80° Filter) 40° (W/65°) 50° (W/45° Lens) 39° (W/25° Lens) 19° |
| (w/80° filter) | 40° |
| (w/65°) | 50° |
| (w/45° lens) | 39° |
| (w/25° lens) | 19° |
| beam angle (w/80° filter) | 40° |
| field angle | (W/80° Filter) 132.9° (W/45° Lens) 69° (W/25° Lens) 36° |
| field angle | (W/80° Filter) 132.9° (W/45° Lens) 69° (W/25° Lens) 36° |
| (w/80° filter) | 132.9° |
| (w/45° lens) | 69° |
| (w/25° lens) | 36° |
| lumens (w/80° filter) | 7,912 |
| lumens (w/65° lens) | 8,505 |
| lumens (w/45° lens) | 8,885 |
| lumens (w/25° lens) | 9,139 |
| illuminance | Illuminance (w/80° filter) 325 lux @ 5 m Illuminance (w/65°) 400 lux @ 5 m Illuminance (w/45° lens) 623 lux @ 5 m Illuminance (w/25° lens) 1,933 lux @ 5 m |
| illuminance | Illuminance (w/80° filter) 325 lux @ 5 m Illuminance (w/65°) 400 lux @ 5 m Illuminance (w/45° lens) 623 lux @ 5 m Illuminance (w/25° lens) 1,933 lux @ 5 m |
| illuminance (w/80° filter) | 325 lux @ 5 m |
| illuminance (w/65°) | 400 lux @ 5 m |
| illuminance (w/45° lens) | 623 lux @ 5 m |
| illuminance (w/25° lens) | 1,933 lux @ 5 m |
| selectable pwm | 600Hz, 1,200Hz, 2,000Hz, 4,000Hz, 6,000Hz, 25 kHz |
| dimmer | Electronic |
| shutter/strobe | Electronic |
| strobe rate | 0 to 30 Hz |
| dim modes | 4 |
| built-in automated programs | Yes |
| dimensions | 13.11 x 9.44 x 13.34 in (333 x 240 x 339 mm) |
| weight | 17.8 lb (8.1 kg) |
| power connection | Bare-wired |
| power input | Hard-wired |
| data connectors | 5-pin XLR, Phoenix connector |
| cable length (power) | 15 ft (4.5 m) |
| control protocol | DMX, W-DMX, RDM |
| dmx channels | 1, 2, 3 or 6 |
| modes/personalities | 4 personalities (1CH, 2CH, 3CH, 6CH) |
| input voltage | 100 to 240 VAC, 50/60 Hz (auto-ranging) |
| power and current | 149 W, 1.314 A @ 120 V, 60 Hz |
| power and current | 141 W, .738 A @ 208 V, 60 Hz |
| power and current | 140 W, .691 A @ 230 V, 50 Hz |
| breaker size | T3.15 A, 250 V |
| certifications | CE, MET, FCC |
| ip rating | IP20, dry location |
| temperature (ambient) | -4 °F to 113 °F (-20 °C to 45 °C) |
