OVATIONH605FCBLK | OVATION H-605FC - BLACK INCLUDES: INTEGRATED 4.5M POWER CORD, INTERCHANGABLE LENS PLATES
OVATIONH605FCBLK
OVATION H-605FC - BLACK INCLUDES: INTEGRATED 4.5M POWER CORD, INTERCHANGABLE LENS PLATES
OVATIONH605FCBLK
OVATION H-605FC - BLACK INCLUDES: INTEGRATED 4.5M POWER CORD, INTERCHANGABLE LENS PLATES
- UM : EA
- Estimated Weight: 21.0
Ovation H-605FC takes full advantage of LED technology, utilizing the Ovation standard RGBA-Lime color palette to enable the fixture to replicate nearly any color with tremendous color rendering, as well as nearly any color temperature of white. Superior convection cooling provides excellent output in a compact package. Ideal for theatrical and house of worship applications, setup and control is now easier than ever with the addition of W-DMX, RDM, adjustable PWM and an easy to navigate OLED full text display. White housing not available in European Markets.
Features:
- Offers interchangeable lens plates to easily adapt beam angles for various mounting heights.
- Achieves exceptionally smooth fades and precise intensity control with 16-bit dimming.
- Supports advanced control protocols including DMX, WDMX, and RDM for programming flexibility.
- Features versatile DMX integration with both 5-pin XLR and terminal block connections.
- Includes a virtual color wheel with presets matched to popular gel colors.
- Ensures flicker-free performance on camera with adjustable Pulse Width Modulation (PWM).
| Light Source | 60 LEDs (12 red, 12 green, 12 blue, 12 amber, 12 lime) 2 to 3 W, (800 mA), 4766 K, 50,000 hours life expectancy |
|---|---|
| Color Temperature (at full) | 5714 K |
| CRI (5600 K) | 87 |
| Dimming Modes | 4 |
| Lumens (w/80° filter) | 4,409 |
| Lumens (w/65° lens) | 5,288 |
| Lumens (w/45° lens) | 5,446 |
| Lumens (w/25° lens) | 5,121 |
| Selectable PWM | 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6000 Hz, 25,000 Hz |
| Power Connection | Bare-wired |
| Power Input | Hard-wired |
| Data Connectors | 5-pin XLR, Phoenix connector |
| Cable Length (power) | 15 ft (4.5 m) |
| Control Protocol | DMX, RDM, W-DMX |
| DMX Channels | 2, 4, 5, 8, 11, 13, 14, 16 or HSV |
| Modes/Personalities | 9 personalities (2, 4, 5, 8, 11, 13, 14, 16, HSV) |
| Certifications | CE, MET, FCC |
| IP Rating | IP20, dry location |
