AH-SQ-6 | SQ6 DIGITAL MIXER-48 INPUT CHANNELS, 96KHZ XCVI FPGA PROCESSING, 25 FADERS/6 LAYERS

  • MAP: $4,999.00 / EA
  • List Price: $6,199.00 / EA
  • Log in to see if custom discounts apply
  • Case Quantity: 1
  • Sign In or Submit RFQ for accurate lead times
SQ6 DIGITAL MIXER-48 INPUT CHANNELS, 96KHZ XCVI FPGA PROCESSING, 25 FADERS/6 LAYERS
SQ6 DIGITAL MIXER-48 INPUT CHANNELS, 96KHZ XCVI FPGA PROCESSING, 25 FADERS/6 LAYERS
SQ6 DIGITAL MIXER-48 INPUT CHANNELS, 96KHZ XCVI FPGA PROCESSING, 25 FADERS/6 LAYERS
Click image to enlarge
SQ6 DIGITAL MIXER-48 INPUT CHANNELS, 96KHZ XCVI FPGA PROCESSING, 25 FADERS/6 LAYERS
SQ6 DIGITAL MIXER-48 INPUT CHANNELS, 96KHZ XCVI FPGA PROCESSING, 25 FADERS/6 LAYERS
SQ6 DIGITAL MIXER-48 INPUT CHANNELS, 96KHZ XCVI FPGA PROCESSING, 25 FADERS/6 LAYERS

AH-SQ-6
SQ6 DIGITAL MIXER-48 INPUT CHANNELS, 96KHZ XCVI FPGA PROCESSING, 25 FADERS/6 LAYERS

  • UM : EA
  • Estimated Weight: 40.0

The SQ-6 is a compact, affordable digital mixer, providing 29 analogue inputs and 16 analogue outputs of local I/O. All SQ series mixers are built around a powerful 48x36 processing matrix, running at 96kHz sample rate and featuring a 96Bit accumulator.

SQ-6 has 24+1 faders, freely assignable across 6 layers, accompanied by a 7” touchscreen and 16 assignable softkeys and 4 assignable soft rotaries for easy operation.

The unique SLink remote audio connection accepts any 48kHz or 96kHz Allen & Heath remote I/O expander or ME interface (SRC is handled by the SLink port).

The audio option slot provides 64 channels of bidirectional audio on either 48kHz or 96kHz Dante or Waves Soundgrid, or an additional SLink port.

Features:

  • 96kHz XCVI FPGA processing
  • 48 input channels
  • 12 stereo mixes + LR
  • 3 stereo matrix
  • 8 stereo FX engines + dedicated stereo returns
  • 24+1 built-in mic preamps
  • 2 stereo line inputs
  • 14 XLR line outputs
  • 2 TRS line outputs
  • AES output
  • 24+1 Faders / 6 Layers
  • 7” capacitive touchscreen
  • 16 assignable SoftKeys
  • 4 assignable Soft Rotaries
  • SQ-MixPad app
  • SQ4You app
  • SLink port for remote audio / expansion
  • 64×64 I/O port for audio networking cards (Dante, Waves, MADI, SLink)
  • SQ-Drive direct recording to USB
  • 32×32 96kHz USB interface
  • Allen & Heath Everything I/O DX-GX System Guide
  • View / Download
